Introduction to HONEYWELL 05704-A-0146
05704-A-0146 Product Overview
The HONEYWELL 05704-A-0146 is a high-reliability 4-channel control card belonging to the 05704 series, specifically designed for industrial automation and PLC system applications. As a key interface component, it serves to connect PLC controllers with various field devices, enabling precise control and signal transmission for industrial processes. This module is engineered with robust industrial-grade components, ensuring stable performance in harsh industrial environments characterized by electromagnetic interference, humidity, and vibration—making it suitable for manufacturing, petrochemical, and marine automation scenarios. Its compact modular design facilitates easy installation on standard System 57 racks, while intuitive status indicators allow for quick monitoring of operational status, simplifying on-site maintenance and troubleshooting. With seamless compatibility with Honeywell PLC systems and flexible configuration capabilities, the 05704-A-0146 provides a dependable control solution for multi-channel industrial process management.
05704-A-0146 Technical Specifications
-
Product Model: 05704-A-0146
-
Product Type: 4-channel Control Card (Honeywell 05704 Series)
-
Core Functions: 4-channel industrial process control; Signal transmission between PLC and field devices; Real-time operation status indication; Compatibility with PLC system integration
-
Input/Output Specifications: Channels: 4 independent control channels; Input Signal Type: 4-20mA analog signal; Output Signal Type: Configurable digital/analog output
-
Power Supply: Operating Voltage: 24VDC; Power Consumption: Typical 3.5W, Maximum 6W
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP67
-
Mechanical Details: Dimensions (L×W×H): Approx. 122mm × 52mm × 132mm; Net Weight: Approx. 0.5kg; Terminal Type: 2.5mm² (14 AWG) field terminals; Mounting Type: System 57 rack plug-in
-
System Compatibility: Compatible with Honeywell PLC systems; Supports standard industrial communication protocols for seamless integration
Recommended HONEYWELL Similar Series Models
-
05704-A-0121: Four-way relay interface card for high-current load switching
-
05704-A-0145: 4-channel control card for 4-20mA input signals
-
05704-A-0144: 4-channel digital light source control card
-
05701-A-0330: Single-channel gas control card for combustible gas detection
-
05701-A-0351: Single-channel interface card with relay output
-
05701-A-0302: Single-channel gas control card with mV input
-
05704F: Four-channel fire control card for flame/smoke detector input
-
05704-A-0122: 8-channel relay interface card with high-current output
-
05704-A-0130: Relay interface card with RS485 communication function
-
05701-A-0360: Single-channel high-isolation gas control card
-
05704-A-0150: Compact four-way relay card for space-constrained installations
-
05704-A-0160: Control card with extended temperature range (-55°C to +85°C)
-
05701-A-0370: Single-channel gas control card with alarm logging function
-
05704-A-0170: Redundant four-way control card for critical systems
