Introduction to HONEYWELL 51305896-200
51305896-200 Product Overview
The HONEYWELL 51305896-200 is a high-performance I/O interface module designed for industrial automation and distributed control systems (DCS). As a key communication link between field devices and central controllers, it enables reliable acquisition and transmission of analog and digital signals, supporting seamless data exchange in complex industrial environments. Engineered with rugged industrial-grade components and advanced anti-interference technology, this module maintains stable operation under conditions of voltage fluctuations, high temperatures, and electromagnetic interference. It seamlessly integrates with Honeywell’s industrial control platforms, widely applied in petrochemical plants, power generation facilities, and manufacturing lines to enhance the efficiency and reliability of control system operations.
51305896-200 Technical Specifications
-
Product Model: 51305896-200
-
Product Type: I/O Interface Module (Industrial Automation Series)
-
Core Functions: Analog and digital signal acquisition, signal transmission between field devices and controllers, signal conditioning, anti-interference processing, fault status monitoring
-
Signal Specifications: Input channels: 8 analog input channels; Output channels: 4 digital output channels; Supported signal types: 4-20mA current signal, 0-10V voltage signal; Signal response time: ≤1ms
-
Power Supply: Operating voltage: 24VDC ±10%; Power consumption: Typical 6W, Maximum 9W; Current consumption: ≤375mA
-
Protection Features: Short-circuit protection for output channels; Over-voltage protection; Reverse polarity protection; Anti-interference: Complies with IEC 61000-4 standards
-
Environmental Limits: Operating temperature: -20°C to +65°C; Storage temperature: -40°C to +85°C; Relative humidity: 5% – 95% (non-condensing); Protection rating: IP40
-
Mechanical Details: Mounting type: DIN rail mounting; Dimensions (L×W×H): 135mm × 85mm × 62mm; Net weight: Approx. 0.4kg; Enclosure material: Flame-retardant ABS
-
Compatibility & Certifications: Seamlessly integrates with Honeywell industrial control systems; Certifications: CE, UL, RoHS Compliant
Recommended HONEYWELL Same-Series Models
-
HONEYWELL 51305897-100: 16-channel analog input module for high-density signal acquisition
-
HONEYWELL 51305898-200: 8-channel digital output module for driving on-site execution devices
-
HONEYWELL 51305900-100: Mixed I/O module with 4 analog input and 4 digital output channels
-
HONEYWELL 51305901-200: High-precision analog input module for 0-5V signal processing
-
HONEYWELL 51305902-100: Digital input module with 16 channels for industrial on-site signal collection
-
HONEYWELL 51305903-200: Analog output module for transmitting standardized 4-20mA control signals
-
HONEYWELL 51305904-100: Relay output module with 8 channels for high-power device control
-
HONEYWELL 51305905-200: Communication interface module supporting RS485 protocol
-
HONEYWELL 51305906-100: High-speed digital I/O module for rapid signal response scenarios
-
HONEYWELL 51305907-200: Isolated analog input module for strong interference industrial environments
-
HONEYWELL 51305908-100: Universal I/O module supporting multiple signal types for flexible configuration
-
HONEYWELL 51305909-200: Power supply module for powering I/O system components
