Introduction to HONEYWELL 51401583-100
51401583-100 Product Overview
The HONEYWELL 51401583-100 is a high-reliability NGI (Network Gateway Interface) card designed specifically for Honeywell distributed control systems (DCS), including Experion PKS and TDC 3000 series. As a critical network communication component, it serves as a bridge between different system segments, enabling seamless data exchange and protocol conversion to ensure coordinated operation of the entire control system. Engineered with rugged industrial-grade materials and advanced anti-interference technology, this card maintains stable performance in harsh industrial environments characterized by electromagnetic interference, temperature fluctuations, and humidity variations. Its modular design facilitates easy installation and maintenance, seamlessly integrating with existing Honeywell DCS configurations. Widely applied in oil and gas, chemical processing, power generation, and water treatment industries, it plays a vital role in enhancing the connectivity and operational reliability of industrial control systems.
51401583-100 Technical Specifications
-
Product Model: 51401583-100
-
Product Type: NGI Card (Network Gateway Interface Card, DCS Series)
-
Core Functions: System segment data exchange, communication protocol conversion, network gateway connection, data transmission monitoring, system compatibility enhancement
-
Communication Specifications: Supported interfaces: Compatible with Honeywell DCS network protocols; Data transmission rate: Adaptable to system communication requirements; Supports reliable data exchange between different control system segments
-
Power Supply: Operating voltage: 24VDC ±10%; Power consumption: Typical 7W, Maximum 10W; Current consumption: ≤417mA
-
Protection Features: Short-circuit protection; Over-voltage protection; Reverse polarity protection; Anti-interference: Complies with IEC 61000-4 standards
-
Environmental Limits: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Relative humidity: 5% – 95% (non-condensing); Protection rating: IP20
-
Mechanical Details: Mounting type: Honeywell DCS standard rack mounting; Dimensions (L×W×H): 30.5cm × 15.8cm × 7.6cm; Net weight: Approx. 0.8kg; Enclosure material: Flame-retardant metal
-
Compatibility & Certifications: Seamlessly integrates with Honeywell Experion PKS (C200, C300) and TDC 3000 DCS; Compatible with various Honeywell DCS modules; Certifications: CE, UL, RoHS Compliant; 12-month warranty
Recommended HONEYWELL Same-Series Models
-
HONEYWELL 51401583-200: NGI card variant for extended network communication scenarios
-
HONEYWELL 51403427-275 (TK-IOLI01): I/O link interface module for DCS signal transmission
-
HONEYWELL 51309288-225 (TK-PRR021): Redundant module enhancing system fault tolerance
-
HONEYWELL 51405046-175 (CC-PCNT01): Control processor module for distributed control systems
-
HONEYWELL 51309512-175 (TK-FTEB01): Fault-tolerant Ethernet bridge for reliable network communication
-
HONEYWELL 51308363-175 (CC-TAIX01): PM I/O card for analog input signal processing
-
HONEYWELL 51308351-175 (CC-TAOX01): PM I/O card for analog output signal transmission
-
HONEYWELL 51304453-150 (MC-TAIH02): FTA card for UCN system signal termination
-
HONEYWELL 96978373 (TC-IXR061): I/O link interface module with redundant communication support
-
HONEYWELL 8C-PAIH51: HART analog input module for high-precision signal acquisition
-
HONEYWELL 51304485-150: Digital input module for industrial on-site signal collection
-
HONEYWELL TC-IDD321: DC input module for Experion PKS system signal acquisition
