Introduction to HONEYWELL 51403645-100
51403645-100 Product Overview
The HONEYWELL 51403645-100 is a high-reliability I/O link interface module specifically designed for Honeywell TDC 3000 distributed control systems (DCS). As a critical communication intermediary between I/O modules and central control units, it enables stable and efficient data transmission, supporting seamless signal exchange in complex industrial automation environments. Engineered with rugged industrial-grade components and advanced anti-interference technology, this module maintains consistent performance under harsh conditions such as voltage fluctuations, electromagnetic interference, and extreme temperatures. Its modular and rack-mountable design facilitates easy integration into existing TDC 3000 system setups, ensuring convenient installation and maintenance. Widely applied in oil and gas, chemical processing, power generation, and water treatment industries, it plays a vital role in enhancing the reliability and operational efficiency of distributed control systems.
51403645-100 Technical Specifications
-
Product Model: 51403645-100
-
Product Type: I/O Link Interface Module (TDC 3000 Series)
-
Core Functions: Facilitates data transmission between I/O modules and central controllers, signal conditioning, communication protocol conversion, fault diagnosis and monitoring, system synchronization
-
Communication Specifications: Supported interfaces: RS-485, I/O link; Data transmission rate: Up to 1Mbps; Communication distance: Max 1000m (RS-485)
-
Power Supply: Operating voltage: 24VDC ±10%; Power consumption: Typical 8W, Maximum 12W; Current consumption: ≤500mA
-
Protection Features: Short-circuit protection; Over-voltage protection; Reverse polarity protection; Anti-interference: Complies with IEC 61000-4 standards
-
Environmental Limits: Operating temperature: -40°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5% – 95% (non-condensing); Protection rating: IP20
-
Mechanical Details: Mounting type: TDC 3000 standard rack mounting; Dimensions (L×W×H): 32.5cm × 16.8cm × 8.2cm; Net weight: Approx. 0.95kg; Enclosure material: Flame-retardant metal
-
Compatibility & Certifications: Seamlessly integrates with Honeywell TDC 3000 DCS; Compatible with various TDC 3000 I/O modules; Certifications: CE, UL, RoHS Compliant; 12-month warranty
