Introduction to HONEYWELL 51404170-175
51404170-175 Product Introduction
The HONEYWELL 51404170-175 is a high-reliability industrial control module, specifically designed for critical process control systems in industrial automation. As an integral component of Honeywell’s industrial control product lineup, it functions as a key link between field sensing devices and upper-level control units, enabling accurate signal conversion and stable data transmission. This module supports multiple signal types to adapt to diverse industrial scenarios, providing precise control logic execution to ensure the stability and efficiency of production processes. Equipped with built-in diagnostic functions and status monitoring indicators, it allows for rapid fault detection and maintenance, effectively reducing system downtime. Its rugged industrial design ensures stable operation under harsh conditions such as extreme temperatures, electromagnetic interference, and vibration.
51404170-175 Technical Specifications
-
Product Model: 51404170-175
-
Product Type: Industrial Control Module (Honeywell Industrial Automation Series)
-
Core Functions: Multi-type signal conversion and transmission; Precise control logic execution; Built-in fault diagnosis and status monitoring; High-reliability data communication; System integration and expansion
-
Signal & Connection: Input Signal Types: Analog (4-20mA, 0-10V) and Digital; Output Signal Types: Configurable analog/digital output; Connection Mode: Plug-in terminal connection; Installation Mode: DIN rail or rack mounting
-
Electrical Specifications: Power Supply: 24VDC (±10%); Power Consumption: ≤15W; Signal Accuracy: ±0.1% full scale; Response Time: ≤200ms; Certifications: CE, IEC 61010-1, UL
-
Environmental Ratings: Operating Temperature: -40°C to +75°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 5g (10-2000Hz); Shock Resistance: 30g (11ms)
-
Mechanical Details: Housing Material: Industrial-grade aluminum alloy; Dimensions: 120mm × 80mm × 45mm; Net Weight: Approx. 250g; Protection Rating: IP20
-
System Compatibility: Fully compatible with Honeywell TDC3000, Experion PKS DCS systems and industrial control networks; Suitable for integration into petroleum, chemical, power generation, and process manufacturing industry control setups
Recommended Honeywell Models
-
51404171-100: Industrial control module with enhanced communication capability for large-scale data transmission
-
51404172-200: Multi-channel analog input module for high-precision signal acquisition
-
51404173-300: Digital output module with high-load driving capability for heavy-duty equipment control
-
51304511-200: Analog input/output module for flexible signal conversion and transmission
-
51304512-100: High-precision analog input module for sensitive sensor data collection
-
51304513-200: Stable analog output module for actuator control
-
51196655-100 ACX633: ACX series power supply module for reliable system power support
-
CC-PAIH01: Analog input module with HART protocol for intelligent sensor integration
-
CC-PAOX01: Analog output module for precise actuator regulation
-
CC-PWRR01: 20A redundant DC power module for cabinet-level power protection
-
CC-PCNT01: C300 control processor module for core process control
-
TC-FTEB01: FTE bridge module for network redundancy and continuous communication
-
51305072-200: CLCN series communication module for LCN network connection
-
CC-PDIS01: Digital input module with SOE function for event sequence recording
-
MC-PFBS01: Fieldbus interface processor module for multi-network integration
