Introduction to HONEYWELL 8C-PCNT02 51454363-275
8C-PCNT02 51454363-275 Product Overview
The HONEYWELL 8C-PCNT02 51454363-275 is a high-performance control pulse card module under the Honeywell 8C series, specifically engineered for industrial automation and distributed control systems (DCS). As a core component for pulse signal management, it specializes in receiving, processing, and counting pulse signals from sensors, encoders, and other field devices, delivering precise data support for process monitoring, control, and data acquisition. Equipped with multiple independent input channels, this module can simultaneously handle signals from various pulse sources, enhancing its adaptability in complex automation scenarios. Its redundant design and industrial-grade construction ensure stable operation in harsh environments with high temperature, humidity, and dust—common in manufacturing, energy, chemical, and automotive industries. Featuring flexible software-configurable parameters (e.g., pulse input mode, counter resolution), it allows easy customization to meet specific application needs.
8C-PCNT02 51454363-275 Technical Specifications
-
Product Model: 8C-PCNT02 51454363-275
-
Product Type: Control Pulse Card Module (Honeywell 8C Series)
-
Core Functions: Pulse signal receiving, processing and counting; Multi-channel concurrent signal handling; High-precision measurement; Software-configurable parameters; Safety interlock and alarm functions; Data collection and analysis
-
Signal & Connection: Frequency Range: 0.01Hz to 100kHz; Pulse Width: 10μs to 10ms; Communication Protocols: RS-485; Interfaces: Ethernet, RS-232; Multiple independent input channels
-
Electrical Specifications: Operating Voltage: 24VDC; Power Supply Requirements: +5V, +12V, +15V; Power Consumption: 5W, Maximum Current 50mA; Processor: 32-bit RISC microprocessor; Memory: 8MB RAM, 2MB Flash
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP20
-
Mechanical Details: Dimensions (L×W×H): 230mm × 130mm × 65mm; Net Weight: Approx. 2.5kg; Housing: Industrial-grade material; Mounting Type: 6U VMEbus module, vertical installation
-
System Compatibility: Fully compatible with Honeywell Experion PKS systems and C300 controllers; Complies with IEC 61131-3 standard; Suitable for manufacturing, energy, chemical, automotive, and food & beverage industry control setups
Recommended HONEYWELL Similar Series Models
-
8C-PCNT03: Upgraded control pulse card module with enhanced counting frequency and expanded channel capacity
-
8C-PDILA1: 32-channel digital input module for high-precision discrete signal collection and processing
-
8C-PAOHA1: Analog output module with HART protocol support for precise field actuator control
-
8C-PDIL01: 24VDC digital input module with strong anti-interference capability for harsh industrial environments
-
8C-PDOB01: Digital output module with relay switching function for heavy-load field device driving
-
8C-PAIH01: Analog input module with HART communication for accurate process parameter acquisition
-
8C-CCN01: High-speed network communication module for data transmission between 8C series modules
-
8C-PWRR01: Redundant power supply module ensuring stable power input for 8C series systems
-
8C-TAIX01: Analog input module backplane facilitating signal transmission for 8C series
-
8C-TDOB01: Digital output module backplane supporting 32-channel 24VDC signal output
-
8C-PDIL02: 16-channel digital input module with fast sampling rate for real-time monitoring
-
8C-PAOX01: Multi-channel analog output module without HART protocol for general industrial control
-
8C-PDIO01: Integrated digital input/output module for mixed signal processing scenarios
-
8C-COMM01: Multi-protocol communication module enhancing system interoperability
