Introduction to HONEYWELL 900ES1-0100
900ES1-0100 Product Overview
The HONEYWELL 900ES1-0100 is a high-precision signal processing module from the 900ES series, tailored for industrial automation and process control scenarios. It specializes in conditioning, filtering, and amplifying analog and digital signals from field sensors and transmitters, ensuring accurate data relay to upper-level DCS or PLC systems. With excellent anti-interference capabilities, it effectively mitigates electromagnetic and radio frequency interference, enabling stable operation in petroleum, chemical, power generation, and manufacturing industries. Its compact modular design allows easy installation in control cabinets, while user-friendly configuration software simplifies parameter setup and calibration. Built with robust industrial-grade materials, it maintains reliability under extreme temperature and humidity conditions, making it suitable for critical process monitoring requiring high precision.
900ES1-0100 Technical Specifications
-
Product Model: 900ES1-0100
-
Product Type: Industrial Control Signal Processing Module (Honeywell 900ES Series)
-
Core Functions: Analog/digital signal conditioning and conversion; Signal filtering and amplification; High-precision data acquisition; Anti-interference signal processing; Parameter configuration and calibration; Fault self-diagnosis
-
Signal & Connection: Input Signal Type: 4-20mA analog signal, 0-10V analog signal; Output Signal Type: Isolated 4-20mA/0-10V; Communication Interface: RS485 (Modbus RTU protocol); Connection Type: Screw terminal
-
Electrical Specifications: Operating Voltage: 24VDC ±10%; Power Consumption: Maximum 3W; Input Impedance: ≥1MΩ; Output Load: 0-500Ω; Measurement Accuracy: ±0.1% of full scale
-
Environmental Ratings: Operating Temperature: -20°C to +65°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP20 (when installed in control cabinet)
-
Mechanical Details: Dimensions (L×W×H): 110mm × 80mm × 35mm; Net Weight: Approx. 0.2kg; Housing Material: Flame-retardant ABS plastic; Mounting Type: DIN rail mounting
-
System Compatibility: Compatible with Honeywell Experion PKS DCS and other mainstream industrial control systems; Suitable for integration into petroleum, chemical, power generation, and manufacturing industry control setups
Recommended HONEYWELL Similar Series Models
-
900ES1-0200: Dual-channel signal processing module for simultaneous handling of two independent input signals
-
900ES1-0300: High-speed signal acquisition module with enhanced sampling rate for real-time monitoring
-
900ES2-0100: Isolated signal conversion module with strong anti-interference capability for complex industrial environments
-
900ES2-0200: Multi-range signal processing module supporting configurable input/output signal ranges
-
900ES3-0100: Digital signal processing module specialized in switching signal detection and conversion
-
900ES3-0200: Relay output signal module for driving field executive components
-
900ES4-0100: Networked signal processing module with Ethernet interface for remote data transmission
-
900ES5-0100: Temperature signal processing module dedicated to RTD/thermocouple sensor signal conversion
-
900ES5-0200: Pressure signal conditioning module for high-precision pressure sensor data acquisition
-
900ES6-0100: Signal splitter module for distributing one input signal to multiple output channels
-
900ES3-0100: Digital signal processing module specialized in switching signal detection and conversion
-
900ES3-0200: Relay output signal module for driving field executive components
-
900ES4-0100: Networked signal processing module with Ethernet interface for remote data transmission
-
900ES4-0200: Redundant signal processing module ensuring uninterrupted operation for critical applications
-
900ES5-0100: Temperature signal processing module dedicated to RTD/thermocouple sensor signal conversion
-
900ES5-0200: Pressure signal conditioning module for high-precision pressure sensor data acquisition
-
900ES6-0100: Signal splitter module for distributing one input signal to multiple output channels
-
900ES6-0200: Signal isolation amplifier module with enhanced isolation voltage for high-noise environments
