Introduction to HONEYWELL CC-IP0101 51410056-175
CC-IP0101 51410056-175 Product Overview
The HONEYWELL CC-IP0101 (Material Code: 51410056-175) is a high-reliability Profibus DP gateway module under the Experion product family, tailored for seamless integration with Honeywell C300 controllers. As a key communication bridge in industrial automation, it enables efficient data exchange between C300 controllers and up to 127 Profibus DP slave devices. With a modular design and optional redundancy, it supports flexible network configuration via adjustable baud rates (9.6 kbps to 12 Mbps), adapting to diverse transmission needs. Built with rugged industrial components, it maintains stable performance in harsh environments and shares consistent power, grounding, and environmental traits with other Series 8 components, widely used in process control, manufacturing, and energy sectors to boost DCS interoperability and reliability.
CC-IP0101 51410056-175 Technical Specifications
-
Product Model: CC-IP0101 (Material Code: 51410056-175)
-
Product Type: Profibus DP Gateway Module (Experion Series, C300 Controller Compatible)
-
Core Functions: Data exchange between C300 controller and Profibus DP slaves, network traffic monitoring, fault diagnosis, data filtering, optional redundancy
-
Communication: Up to 127 Profibus DP slave devices supported; 9.6 kbps – 12 Mbps adjustable baud rate; Master/slave modes; 2 DP networks per module
-
Power Supply: 24VDC operating voltage; Power consumption consistent with Series 8 components
-
Protection: Optional redundancy for critical applications; Industrial-grade anti-interference capability
-
Environment: Operating temp: -20°C to +60°C; Storage temp: -40°C to +85°C; 5%-95% relative humidity (non-condensing)
-
Mechanical: Series 8 IOTA compatible mounting; Dimensions: 190mm×69mm×23mm (7.5in×2.7in×0.9in); Net weight: Approx. 0.2kg
-
Compatibility & Warranty: Integrates with Honeywell C300 controllers and Experion DCS; Complies with industrial standards; 1-year warranty
Recommended HONEYWELL Same-Series Models
-
HONEYWELL CC-PDIL01: 24V digital input module for reliable signal collection
-
HONEYWELL CC-PDIH01: High-voltage digital input module for high-voltage signal scenarios
-
HONEYWELL CC-PCF901: 8-port + 1 uplink control firewall for network security
-
HONEYWELL CC-PAO01: Analog output module for standardized actuator signals
-
HONEYWELL CC-PAOH51: HART-enabled analog output module
-
HONEYWELL CC-PAIX02: High-level differential analog input module for precise signal acquisition
-
HONEYWELL CC-PAIN01: High-level analog input module for high-precision collection
-
HONEYWELL CC-PAIM01: 64-point low-level analog multiplexer for multi-channel processing
-
HONEYWELL CC-PAIL51: Low-level analog input IOM module
-
HONEYWELL CC-PAIH51: HART high-level analog input module
-
HONEYWELL CU-PWPR20: 20A redundant power supply module
-
HONEYWELL CC-PUIO31: Universal I/O module for multi-signal scenarios
-
HONEYWELL CC-IP0201: Industrial Ethernet switch module for high-speed network connectivity
-
HONEYWELL CC-PDOR01: Digital output relay module for on-site device control
-
HONEYWELL CC-PDID01: Digital input discrete module for discrete signal processing
