Introduction to HONEYWELL CC-IP0101
CC-IP0101 51410056-175 Product Overview
The HONEYWELL CC-IP0101 51410056-175 is a high-performance industrial Ethernet communication module belonging to the CC series, specifically engineered for seamless data exchange in industrial control systems. It serves as a critical connectivity bridge between Honeywell DCS controllers and IP-based field devices, enabling reliable transmission of control signals and process data over Ethernet networks. Equipped with advanced network communication protocols and robust anti-interference technology, this module ensures stable data transfer even in harsh industrial environments with strong electromagnetic interference and voltage fluctuations. Its compact and standardized design supports easy integration into existing Honeywell control system architectures, simplifying installation and maintenance processes. Featuring built-in self-diagnostic and network monitoring capabilities, it provides real-time status updates of network connections and module operations, helping maintenance teams quickly identify and resolve communication faults to minimize system downtime.
CC-IP0101 51410056-175 Technical Specifications
-
Product Model: CC-IP0101 51410056-175
-
Product Type: Industrial Ethernet Communication Module (CC Series)
-
Core Functions: Industrial Ethernet data transmission; Protocol conversion for DCS-IP device communication; Real-time network status monitoring; Built-in self-diagnosis & fault alarm; Anti-interference data transmission
-
Communication Specifications: Network Protocol: TCP/IP, UDP, Modbus TCP; Ethernet Port: 2 x 10/100 Mbps RJ45; Communication Rate: Up to 100 Mbps; Latency: ≤5ms; Support for Unicast/Multicast/Broadcast
-
Power Supply: Operating Voltage: 24VDC (±10%); Power Consumption: Typical 6W, Maximum 8W
-
Protection Features: Over-voltage protection (up to 36VDC); Short-circuit protection; 2500VAC electrical isolation between network and power; EN 55022 Class A anti-EMI/RFI compliance
-
Environmental Limits: Operating Temperature: -30°C to +65°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 5g (10-500Hz)
-
Mechanical Details: Mounting Type: 35mm standard DIN rail; Protection Rating: IP20; Dimensions (L×W×H): Approx. 105mm × 80mm × 45mm; Net Weight: Approx. 0.3kg
-
Compatibility: Compatible with Honeywell Experion PKS, C200/C300 controllers; Complies with IEEE 802.3, IEC 61131-2 standards; CE, UL, RoHS Certified
Recommended Honeywell Same-Series Models
-
CC-IP0102: 4-port industrial Ethernet communication module
-
CC-IP0103: High-speed Ethernet module (latency ≤2ms)
-
CC-IP0104: Redundant Ethernet communication module for high-reliability systems
-
CC-IP0105: Wireless Ethernet (Wi-Fi) communication module
-
CC-IP0106: Protocol conversion module supporting Profinet & Modbus TCP
-
CC-IP0107: Compact Ethernet module for limited-space installations
-
CC-IP0108: Industrial Ethernet switch module with 8 ports
-
CC-IP0109: Low-power Ethernet communication module for energy-saving systems
-
CC-IP0110: Safety-rated Ethernet module for emergency shutdown systems
-
CC-IP0111: Extended temperature range Ethernet module (-40°C to +75°C)
-
CC-IP0112: Ethernet module with built-in surge protection (6kV)
-
CC-IP0113: Gigabit industrial Ethernet communication module
-
CC-IP0114: Multi-protocol Ethernet module (Modbus TCP, Ethernet/IP)
-
CC-IP0115: Industrial Ethernet gateway module for remote monitoring
-
CC-IP0116: High-isolation (3000VAC) Ethernet communication module
-
CC-IP0117: Ethernet module with SD card data logging function
-
CC-IP0118: 2-port PoE industrial Ethernet communication module
-
CC-IP0119: Ethernet module compatible with legacy Honeywell DCS systems
-
CC-IP0120: Industrial Ethernet bridge module for long-distance transmission
