Introduction to HONEYWELL CC-PAIH02
CC-PAIH02 Product Introduction
The HONEYWELL CC-PAIH02 is a high-performance analytical input module under the Honeywell Experion PKS series, specifically designed for industrial process control systems. As a key bridge between on-site analytical instruments and DCS controllers, it specializes in collecting and processing weak analog signals from devices like pH electrodes, dissolved oxygen sensors, conductivity meters, and turbidity meters. By converting these signals into stable, linear digital data recognizable by Honeywell controllers, it provides reliable data support for process optimization and quality control. Equipped with 4 independent configurable channels, the module can simultaneously monitor multiple analytical parameters, adapting to complex industrial scenarios. It integrates built-in signal amplification, filtering, and linearization circuits to effectively suppress electromagnetic interference and ensure high-precision acquisition.
CC-PAIH02 Technical Parameters
-
Product Model: CC-PAIH02
-
Product Type: Analytical Input Module (Honeywell Experion PKS Series)
-
Core Functions: 4-channel independent analytical signal acquisition; Weak signal amplification & filtering; Signal linearization processing; Real-time fault diagnosis (open circuit, short circuit, over-range); HART protocol support for multi-variable instruments; Seamless adaptation with CC-TCNT01 base module
-
Connection Specifications: Jack panel process side connection; Direct card-mounted on CC-TCNT01 4-loop industrial base module; PROFINET interface; Compliant with IEC 61000-6-2 anti-interference standard
-
Electrical Specifications: Power Supply: 24V DC; Input Signal Types: ±100mV (pH/ORP), 0~20mA/4~20mA (dissolved oxygen/turbidity), 0~10V DC (concentration), resistance (conductivity); Accuracy: Voltage ±0.05% FS, Current ±0.02% FS, Resistance ±0.1Ω; Isolation: 1500V AC; Resolution: 16-bit; Certifications: CE, CCC compliant
-
Environmental Ratings: Operating Temperature: -25°C to +60°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection: Electromagnetic interference resistance
-
Mechanical Details: Housing Material: Industrial-grade plastic; Dimensions: 120mm × 80mm × 35mm; Weight: Approximately 0.48kg; Installation: Plug-and-play on CC-TCNT01 base module
-
System Compatibility: Fully compatible with Honeywell Experion PKS DCS system and CC-TCNT01 base module; Suitable for water treatment, petrochemical, pharmaceutical, food & beverage industries
Recommended Honeywell Same-Series Models
-
CC-PAIH01: Basic analytical input module for standard signal acquisition
-
CC-PAIH03: High-precision analytical input module with extended measurement range
-
CC-PAOH02: Analytical output module for control signal transmission
-
CC-TCNT01: 4-loop industrial base module compatible with CC-PAIH02
-
CC-PCNT01: DCS controller communication module for data exchange
-
CC-PCNT02: High-performance controller module with multiple control algorithms
-
CC-TDIL01: Digital input module for industrial on-site discrete signal collection
-
CC-TDOB11: Digital output module for driving on-site actuators
-
CC-PDOB01: DO module for industrial process control
-
CC-TAOX11: Analog output module for process control signals
-
CC-IP0101: Integrated input/output card module for signal processing
-
CC-PAIN01: 16-channel high-level analog input module (non-HART)
-
CC-PAONO1: 16-channel analog output module (non-HART)
-
CC-FMMX01: Fiber optic communication module for long-distance data transmission
-
CC-PCF901: Control firewall module for system security protection
-
51405038-375: Analog input module with consistent system compatibility
-
51405038-475: High-speed digital input card module
