Introduction to HONEYWELL CC-PCF901 51405047-175
CC-PCF901 51405047-175 Product Overview
The HONEYWELL CC-PCF901 51405047-175 is a dedicated control firewall module for the Experion PKS C300 system, acting as a critical security barrier in industrial distributed control systems (DCS). It safeguards the C300 controller from unauthorized access and cyber threats by filtering and regulating data communication between the controller and external networks. Operating on predefined security policies, it ensures only legitimate control signals and data packets are transmitted, maintaining process integrity and real-time performance. With a modular design, it enables easy configuration and seamless integration with the CC-HCN911 backplane and other C300 components. Its robust industrial-grade build ensures stable operation in harsh environments with electromagnetic interference and temperature fluctuations, suitable for petroleum, chemical and power generation industries. Built-in self-diagnostic functions with fault indicators facilitate timely maintenance and continuous security protection.
CC-PCF901 51405047-175 Technical Specifications
-
Product Model: CC-PCF901 51405047-175
-
Product Type: Control Firewall Module (Honeywell Experion PKS C300 Series)
-
Core Functions: FTE control firewall protection; Unauthorized access prevention; Data communication filtering; Security policy enforcement; Built-in self-diagnosis with fault indication
-
Signal & Connection: Supported Interfaces: Ethernet, Profibus, RS-485; Connection: C300 system backplane compatible; Integration: Seamless docking with CC-HCN911 backplane; I/O Ports: 9 (8+1 FTE switch ports)
-
Electrical Specifications: Operating Voltage: 24VDC (powered by C300 system); Power Consumption: Low power; Isolation: Enhanced anti-EMI electrical isolation; Certification: CE certified
-
Environmental Ratings: Operating Temperature: 0°C to +70°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 0% – 90% (non-condensing); Protection Rating: IP20 (in standard control cabinet)
-
Mechanical Details: Housing Material: Industrial-grade corrosion-resistant plastic; Mounting Type: C300 system rack mounting (control room); Dimensions: C300 series standard; Net Weight: Approx. 0.3kg
-
System Compatibility: Fully compatible with Honeywell Experion PKS C300 system and CC-HCN911 backplane; Works with CC-PCNT01 controller; Suitable for petroleum, chemical, power generation and metallurgical industries
Recommended HONEYWELL Similar Series Models
-
CC-PCNT01: Core C300 control processor module for industrial process control
-
CC-PCNT02: Advanced C300 controller module with enhanced performance and integration
-
CC-TCF901: Control firewall backplane for CC-PCF901 module installation
-
CC-HCN911: Backplane supporting CC-PCNT01 and CC-PCF901 co-installation
-
CC-IP0101: C300 gateway module for system data exchange and network connection
-
CC-PDIL01: 32-channel digital input module for discrete signal acquisition
-
CC-PDOB01: 32-channel digital output module for driving field devices
-
CC-PAIH01: Analog input module with HART protocol for intelligent sensor data collection
-
CC-PAOX01: Non-HART analog output module for stable control signal output
-
CC-PDIS01: Digital input module with SOE function for event sequence recording
-
CC-PAIM01: 64-channel low-level analog input module for RTD and thermocouple processing
-
CC-TCNT01: C300 controller backplane for module mounting and power supply
-
CC-PWRR01: 20A redundant DC power module for cabinet-level protection
-
CC-SCMB02: C300 memory backup battery module with built-in battery
-
CC-TPOX01: Gateway module backplane for CC-IP0101 integration
-
CC-PPIX01: Pulse input module for high-speed pulse signal processing
-
CC-FTEB01: FTE network interface module for Experion PKS network connection
-
DC-TCNT01: Alternative C300 controller backplane for flexible configuration
-
CC-PWRB01: Redundant 20A DC power module for stable system power supply
