Introduction to HONEYWELL CC-PDIL01 51405040-175
CC-PDIL01 51405040-175 Product Overview
The HONEYWELL CC-PDIL01 51405040-175 is a high-reliability digital I/O module from the Experion PKS series, tailored for industrial automation and process control. As a key interface between field devices and upper controllers, it offers 32 configurable digital input channels and multiple output channels, efficiently handling discrete signals from sensors and switches while driving actuators and alarms. Equipped with advanced optoelectronic isolation, it suppresses electromagnetic interference for stable operation in harsh industrial environments. Its wide 18-30VDC input voltage range adapts to fluctuating power conditions, and high-speed signal acquisition (5ms±20% absolute delay) meets real-time feedback requirements. Seamlessly compatible with Honeywell C300 controllers and Experion PKS DCS, it enables easy system expansion, with LED indicators simplifying on-site monitoring and maintenance. It performs reliably in petroleum, chemical, power generation and manufacturing industries.
CC-PDIL01 51405040-175 Technical Specifications
-
Product Model: CC-PDIL01 51405040-175
-
Product Type: Digital Input/Output (I/O) Module (Honeywell Experion PKS Series)
-
Core Functions: 32-channel digital signal input; Multi-channel digital signal output; High-speed signal acquisition and response; Optoelectronic isolation protection; Real-time signal status monitoring; Seamless system integration
-
Signal & Connection: Input Signal: 18-30VDC discrete signals; Output Signal: Discrete digital signals; Supported Protocols: HART, FOUNDATION Fieldbus, Modbus RTU; Connection Type: Screw terminals; Absolute Delay: 5ms±20%; Input Impedance: 4.2kΩ
-
Electrical Specifications: Operating Voltage: 24VDC; Power Consumption: 50mA; Isolation Protection: 1500VAC RMS or ±1500VDC optoelectronic isolation; Turn-on Detection: Minimum 13VDC / 3mA; Turn-off Detection: Maximum 5VDC / 1.2mA
-
Environmental Ratings: Operating Temperature: -40°C to +70°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP20 (when installed in control cabinet)
-
Mechanical Details: Housing Material: Industrial-grade corrosion-resistant plastic; Mounting Type: DIN rail mounting; Dimensions (L×W×H): 50mm × 80mm × 25mm; Net Weight: Approx. 0.1kg
-
System Compatibility: Fully compatible with Honeywell C300 controllers and Experion PKS DCS; Suitable for integration into petroleum, chemical, power generation, manufacturing, and transportation industry control setups
