Introduction to HONEYWELL CC-PDIL01
CC-PDIL01 Product Overview
The HONEYWELL CC-PDIL01 is a high-performance enhanced digital input module designed specifically for Honeywell C-series industrial automation systems, including ControlEdge™ PLC and Experion® PKS DCS. As a key data acquisition component in harsh industrial control environments, it specializes in collecting real-time switching signals from on-site devices such as proximity sensors, limit switches, emergency stop buttons, and photoelectric sensors, then converting these signals into digital formats recognizable by the system controller. This module features a robust circuit design with enhanced anti-interference capability, enabling it to maintain accurate signal acquisition even in environments with strong electromagnetic radiation and severe voltage fluctuations. Equipped with multiple independent input channels, it supports simultaneous signal collection for multiple devices, meeting the requirements of complex control systems.
CC-PDIL01 Technical Specifications
-
Product Model: CC-PDIL01
-
Product Type: Enhanced Digital Input Module (C-series I/O Series)
-
Core Functions: Collects real-time switching signals from on-site devices; Converts analog switching signals to digital signals; Provides enhanced signal filtering and anti-interference processing; Enables real-time monitoring of signal status and fault diagnosis
-
Input Specifications: Number of Input Channels: 32; Input Type: Dry contact / Wet contact (configurable); Supported Signal Voltage: 24VDC; Input Current: 3mA per channel (typical); Response Time: ≤0.8ms; Input Impedance: ≥15kΩ
-
Power Supply: Operating Voltage: 24VDC ±10%; Power Consumption: Typical 5W, Maximum 7W
-
Protection Features: Over-voltage protection (up to 40VDC); Reverse polarity protection; Short-circuit protection; Electrical isolation: 3000VAC (between channels and system)
-
Environmental Limits: Operating Temperature: -40°C to +75°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 5g (10-500Hz)
-
Mechanical Details: Mounting Type: DIN rail mounting (via C-series base module); Protection Rating: IP20
-
Compatibility & Certifications: Seamlessly integrates with Honeywell C-series base modules, ControlEdge™ PLC and Experion® PKS DCS; Complies with IEC 61131-2 and IEC 61010-1 standards; RoHS Compliant
Recommended Honeywell Same-Series Models
-
HONEYWELL CC-TCNT01: 4-loop base module for integrating C-series I/O modules and distributing power
-
HONEYWELL CC-TDIL01: Standard digital input module for general industrial signal acquisition scenarios
-
HONEYWELL CC-TDOB01: 32-channel digital output module for transmitting switching control signals to field actuators
-
HONEYWELL CC-PDOB01: 16-channel enhanced load digital output module for heavy-load equipment control
-
HONEYWELL CC-TAIM01: Low-level analog input module for acquiring temperature, pressure and flow signals
-
HONEYWELL CC-TAON01: Analog output module for transmitting standardized 4-20mA/0-10V control signals
-
HONEYWELL CC-PAIH01: HART analog input module for high-precision process signal acquisition and communication
-
HONEYWELL CC-PAOX01: Standard analog output module for stable control signal transmission
-
HONEYWELL CC-PWRR01: 20A redundant power supply assembly for ensuring stable power of system components
-
HONEYWELL CC-TAIX01: Analog input IOTA backplane for integrating multiple C-series analog input modules
-
HONEYWELL CC-TCF901: 9-port control firewall IOTA for securing industrial control network communication
-
HONEYWELL CC-PCNT01: C300 control processor module for executing complex control logic
-
HONEYWELL 51198685-100: Power module dedicated for C-series control and I/O components
