Introduction to HONEYWELL CC-PDOB01 51405043-175
CC-PDOB01 51405043-175 Product Overview
The HONEYWELL CC-PDOB01 51405043-175 is a high-reliability digital output module belonging to the Experion PKS series, specifically engineered for industrial automation and process control systems. As a key component in signal output control, it receives digital commands from upper-level controllers (such as C300) and converts them into stable 24VDC output signals to drive field devices like relays, solenoid valves, and indicators. This module features 32 independent output channels, enabling simultaneous control of multiple devices and meeting the needs of large-scale discrete control applications. Equipped with 1500VAC RMS electrical isolation protection, it effectively suppresses electromagnetic interference and prevents damage from voltage surges, ensuring stable operation in harsh industrial environments with electrical noise, dust, and temperature fluctuations—common in petroleum, chemical, power generation, and manufacturing industries. It supports high-speed and deterministic data transmission via ControlNet protocol, facilitating real-time control and monitoring.
CC-PDOB01 51405043-175 Technical Specifications
-
Product Model: CC-PDOB01 51405043-175
-
Product Type: Digital Output Module (Honeywell Experion PKS Series)
-
Core Functions: 32-channel discrete signal output; Driving relays, valves, and indicators; High-speed real-time data transmission; Channel-level electrical isolation protection; On-site status monitoring; Fault self-diagnosis
-
Signal & Connection: Output Signal: 24VDC discrete signals; Supported Protocol: ControlNet; Connection Type: Screw terminals; Output Channels: 32 independent channels
-
Electrical Specifications: Operating Voltage: 24VDC; Load Voltage: Maximum 30VDC; Load Current: 0.5A per channel (maximum); Isolation Protection: 1500VAC RMS or 1500VDC; Off-state Leakage Current: Maximum 0.5A
-
Environmental Ratings: Operating Temperature: -40°C to +70°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP20 (when installed in control cabinet)
-
Mechanical Details: Housing Material: Industrial-grade corrosion-resistant plastic; Mounting Type: DIN rail mounting; Dimensions (L×W×H): 100mm × 50mm × 20mm; Net Weight: Approx. 0.2kg
-
System Compatibility: Fully compatible with Honeywell C300 controllers and Experion PKS DCS; Suitable for integration into petroleum, chemical, power generation, manufacturing, and transportation industry control setups
