Introduction to HONEYWELL CC-TAIX01 (51308363-175)
51308363-175 CC-TAIX01 Product Overview
The HONEYWELL CC-TAIX01 (Product No.: 51308363-175) is a high-precision analog input module from the CC series, specifically designed for industrial control systems. It serves as a crucial interface between field sensors (such as temperature, pressure, and flow sensors) and Honeywell DCS controllers, converting analog signals collected from the field into digital signals that the controller can process accurately. Equipped with advanced signal conditioning and robust electrical isolation technology, the module effectively resists electromagnetic interference and voltage fluctuations in harsh industrial environments, ensuring stable and reliable data acquisition. Its compact, standardized 35mm DIN rail-mount design enables seamless integration into existing Honeywell control architectures, simplifying installation and on-site maintenance. Built-in self-diagnostic capabilities monitor the operational status of the module and input channels in real-time, helping maintenance teams quickly identify and resolve faults to minimize system downtime.
51308363-175 CC-TAIX01 Technical Specifications
-
Product Model & No.: CC-TAIX01 (51308363-175)
-
Product Type: Analog Input Module (CC Series)
-
Core Functions: Analog-to-digital signal conversion; High-precision field signal acquisition; Signal isolation & anti-interference; Real-time status monitoring; Built-in fault diagnosis & alarm
-
Input Specifications: Input Type: 4-20mA DC / 0-10V DC (configurable per channel); Number of Channels: 4 isolated channels; Input Accuracy: ±0.1% FS; Response Time: ≤1ms; Input Impedance: ≥1MΩ (for voltage input); ≤10Ω (for current input)
-
Power Supply: Operating Voltage: 24VDC (±10%); Power Consumption: Typical 5W, Maximum 7W
-
Protection Features: Over-voltage protection (up to 36VDC); Per-channel short-circuit protection; 2500VAC electrical isolation between channels and power; EN 55022 Class A anti-EMI/RFI compliance
-
Environmental Limits: Operating Temperature: -30°C to +65°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 5g (10-500Hz)
-
Mechanical Details: Mounting Type: 35mm standard DIN rail; Protection Rating: IP20; Dimensions (L×W×H): Approx. 100mm × 75mm × 42mm; Net Weight: Approx. 0.28kg
-
Compatibility: Compatible with Honeywell Experion PKS, C200/C300 controllers; Complies with IEC 61131-2, IEC 61010-1 standards; CE, UL, RoHS Certified
Recommended Honeywell Same-Series Models
-
CC-TAIX02: 8-channel analog input module
-
CC-TAIX03: High-precision analog input (±0.05% FS)
-
CC-TAIX04: Redundant analog input for high-reliability systems
-
CC-TAIX05: Low-power analog input for energy-saving applications
-
CC-TAIX06: Analog input with HART communication
-
CC-TAIX07: Compact analog input for limited-space installations
-
CC-TAIX08: Safety-rated analog input for emergency shutdown systems
-
CC-TAIX09: Extended temperature range (-40°C to +75°C)
-
CC-TAIX10: Analog input with built-in 6kV surge protection
-
CC-TAOX11: 4-channel analog output module
-
CC-TAOX12: 8-channel high-speed analog output
-
CC-TMIX13: Mixed analog input/output (4 in / 4 out)
-
CC-TDIX14: 16-channel digital input module
-
CC-TDOX15: 16-channel digital output module
-
CC-TMIX16: Multi-function mixed analog & digital module
-
CC-TAIX17: High-isolation (3000VAC) analog input
-
CC-TAIX18: Analog input compatible with legacy Honeywell DCS
-
CC-TAIX19: 2-channel ultra-high-precision analog input
-
CC-TAIX20: Analog input with SD card data logging
-
CC-TAIX21: 16-channel high-precision analog input module
-
CC-TDOX22: High-power digital output module
