Introduction to HONEYWELL CC-TAON01 51308371-175
CC-TAON01 51308371-175 Product Introduction
The HONEYWELL CC-TAON01 (Part Number: 51308371-175) is a high-performance analog output module under Honeywell’s ControlEdge™ PLC series, engineered for precise industrial automation control. It serves as a crucial bridge between the PLC processor and field actuators, converting digital control signals into standard analog outputs (voltage or current) to regulate devices like control valves, frequency converters, and servo drives. Featuring 8 independent 16-bit high-resolution output channels, it enables fine-grained control of critical process parameters. With 500VDC electrical isolation, it effectively mitigates electromagnetic interference in harsh industrial environments, ensuring stable signal transmission. Its compact DIN rail-mounted design allows seamless integration with Honeywell control systems, simplifying installation, configuration, and maintenance. This module is widely used in chemical processing, petroleum refining, water treatment, and temperature/pressure control applications where high precision and reliability are paramount.
CC-TAON01 51308371-175 Technical Parameters
-
Product Model: CC-TAON01 (51308371-175)
-
Product Type: Analog Output Module (Honeywell ControlEdge™ PLC Series)
-
Core Functions: 8-channel independent analog output; 16-bit high-resolution signal conversion; 500VDC electrical isolation; Configurable output types (voltage/current); Fast update rate (up to 1ms per channel)
-
Connection Specifications: Compatible with Honeywell ControlEdge™ PLC and Experion® PKS systems; Standard terminal connection; Installation Mode: DIN rail-mounted; Terminal Type: Industrial-grade high-reliability terminals
-
Electrical Specifications: Power Supply: 24VDC (typical); Output Signal Ranges: Voltage (±10V, ±5V, 0-10V, etc.), Current (0-20mA, 4-20mA); Output Accuracy: ±0.25% full scale; Power Consumption: Typical 3W; Certifications: CE, UL
-
Environmental Ratings: Operating Temperature: -40°C to +70°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Electromagnetic Compatibility: Compliant with industrial EMC standards
-
Mechanical Details: Housing Material: Industrial-grade high-strength plastic; Protection Rating: IP20; Installation Space: Compact design for space-saving
-
System Compatibility: Fully compatible with Honeywell ControlEdge™ PLC and Experion® PKS systems; Suitable for chemical, petroleum, water treatment, and process control industries
Recommended Honeywell Same-Series Models
-
CC-TAON11: Redundant analog output module for critical process control with high availability requirements
-
CC-TAIM01: Analog input module for receiving field instrument signals (Honeywell ControlEdge™ PLC series)
-
CC-TDOR01: Digital output relay module for controlling on-site switching actuators
-
CC-TDOI01: Digital input module for receiving discrete signals from field devices
-
CC-TAIX01 (51308363-175): High-precision analog input IOTA terminal board
-
CC-TAOX11 (51308353-175): Redundant analog output IOTA terminal board
-
CC-TAID01 (51306733-175): Analog input terminal board with enhanced signal filtering
-
CC-TDIL01: 24VAC digital input terminal board for discrete signal collection
-
CC-TDIL11: High-density digital input terminal board with SOE function
-
CC-TDOB01: 24VDC digital output terminal board for general applications
-
CC-TDOB11 (51307198-175): Redundant digital output IOTA terminal board
-
CC-TDOR11: Relay output terminal board for high-load field device control
-
CC-TCNT01: Controller baseplate compatible with CC-TAON series modules
-
CC-TAON21: Analog output module with surge protection for harsh environments
-
CC-TAIX61: High-density analog input terminal board for large-scale DCS systems
-
CC-TAOX61: High-density analog output terminal board for large-scale applications
-
CC-TDIL61: High-density 24VAC digital input terminal board
-
CC-TAON31: High-channel-density analog output module for large-scale control systems
-
ControlEdge™ PLC Controller: Core processor unit compatible with CC-TAON01 module
