Introduction to HONEYWELL CC-TAOX11 (51308353-175)
CC-TAOX11 51308353-175 Product Overview
The HONEYWELL CC-TAOX11 (Product No.: 51308353-175) is a high-reliability analog output module from the CC series, tailored for industrial control systems. It serves as a critical interface between Honeywell DCS controllers and field executive devices like actuators and valves, converting digital control signals into precise analog outputs to drive on-site equipment. Equipped with advanced signal conditioning and robust electrical isolation, the module ensures stable signal transmission even in harsh industrial environments with strong electromagnetic interference and voltage fluctuations. Its compact, standardized 35mm DIN rail-mount design enables seamless integration into existing Honeywell control architectures, simplifying installation and maintenance. Built-in self-diagnostic capabilities provide real-time monitoring of operational status and channel health, helping maintenance teams quickly resolve faults and minimize downtime. Suitable for petrochemical, power generation, and precision manufacturing, it delivers a dependable analog output solution for modern process automation.
CC-TAOX11 51308353-175 Technical Specifications
-
Product Model & No.: CC-TAOX11 (51308353-175)
-
Product Type: Analog Output Module (CC Series)
-
Core Functions: Digital-to-analog signal conversion; Precise analog output for field devices; Signal isolation & anti-interference; Real-time status monitoring; Built-in fault diagnosis & alarm
-
Output Specifications: Output Type: 4-20mA DC / 0-10V DC (configurable per channel); Number of Channels: 4 isolated channels; Output Accuracy: ±0.1% FS; Response Time: ≤1ms; Load Capacity: Max 500Ω (for 4-20mA); 1kΩ (for 0-10V)
-
Power Supply: Operating Voltage: 24VDC (±10%); Power Consumption: Typical 5W, Maximum 7W
-
Protection Features: Over-voltage protection (up to 36VDC); Per-channel short-circuit protection; 2500VAC electrical isolation between channels and power; EN 55022 Class A anti-EMI/RFI compliance
-
Environmental Limits: Operating Temperature: -30°C to +65°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 5g (10-500Hz)
-
Mechanical Details: Mounting Type: 35mm standard DIN rail; Protection Rating: IP20; Dimensions (L×W×H): Approx. 100mm × 75mm × 42mm; Net Weight: Approx. 0.28kg
-
Compatibility: Compatible with Honeywell Experion PKS, C200/C300 controllers; Complies with IEC 61131-2, IEC 61010-1 standards; CE, UL, RoHS Certified
Recommended Honeywell Same-Series Models
-
CC-TAOX12: 8-channel analog output module
-
CC-TAOX13: High-precision analog output (±0.05% FS)
-
CC-TAOX14: Redundant analog output for high-reliability systems
-
CC-TAOX15: Low-power analog output for energy-saving applications
-
CC-TAOX16: Analog output with HART communication
-
CC-TAOX17: Compact analog output for limited-space installations
-
CC-TAOX18: Safety-rated analog output for emergency shutdown systems
-
CC-TAOX19: Extended temperature range (-40°C to +75°C)
-
CC-TAOX20: Analog output with built-in 6kV surge protection
-
CC-TAIX21: 4-channel analog input module
-
CC-TAIX22: 8-channel high-speed analog input
-
CC-TMIX23: Mixed analog input/output (4 in / 4 out)
-
CC-TDIX24: 16-channel digital input module
-
CC-TDOX25: 16-channel digital output module
-
CC-TMIX26: Multi-function mixed analog & digital module
-
CC-TAOX27: High-isolation (3000VAC) analog output
-
CC-TAOX28: Analog output compatible with legacy Honeywell DCS
-
CC-TAOX29: 2-channel ultra-high-precision analog output
-
CC-TAOX30: Analog output with SD card data logging
-
CC-TAIX31: 16-channel high-precision analog input module
-
CC-TDOX32: High-power digital output module
