Introduction to HONEYWELL CC-TCNT01 51308307-175
CC-TCNT01 51308307-175 Product Overview
The HONEYWELL CC-TCNT01 51308307-175 is a 4-loop base unit module belonging to the Experion PKS series, specifically designed as a core connecting component for industrial distributed control systems (DCS). It serves as a critical “bridge” between I/O modules and the system bus, undertaking the functions of physical fixation, signal transfer, and installation support for 4-loop I/O modules. This module features a standard 35mm DIN rail mounting design with a snap-on structure, enabling quick installation and removal of compatible I/O modules without tools, which greatly simplifies on-site maintenance and reduces downtime. Equipped with gold-plated contacts and shielded circuits, it ensures stable bidirectional transmission of on-site signals and control commands with minimal signal loss, while its anti-electromagnetic interference performance complies with IEC 61000-6-2 standards, effectively resisting electrical noise from industrial equipment such as inverters and motors.
CC-TCNT01 51308307-175 Technical Specifications
-
Product Model: CC-TCNT01 51308307-175
-
Product Type: 4-Loop Base Unit Module (Honeywell Experion PKS Series)
-
Core Functions: Physical fixation of 4-loop I/O modules; Stable bidirectional signal transfer; Quick I/O module installation and removal; System I/O point expansion; Loop status monitoring and diagnosis
-
Signal & Connection: Supported I/O Modules: 4-loop AI/AO/DI/DO modules of Experion PKS series; Signal Transmission Error: ≤0.1% (analog signal); Signal Response Delay: ≤1ms (digital signal); Connection Type: Gold-plated contacts + screw terminals
-
Electrical Specifications: Power Supply: Provided by compatible I/O modules (typically 24VDC); Isolation Standard: Complies with IEC 61000-6-2 (anti-EMI); Contact Life: ≥1000 insertions/extractions
-
Environmental Ratings: Operating Temperature: 0°C to +60°C; Storage Temperature: -40°C to +70°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP20
-
Mechanical Details: Housing Material: Flame-retardant ABS (UL 94 V-0); Mounting Type: 35mm DIN rail mounting; Dimensions (W×H×D): 12.5mm × 110mm × 150mm; Net Weight: Approx. 0.15kg
-
System Compatibility: Fully compatible with Honeywell Experion PKS DCS and C300 controllers; Suitable for integration into petroleum, chemical, power generation, metallurgical, and transportation industry control setups
Recommended HONEYWELL Similar Series Models
-
CC-TAIX01: 4-loop analog input module for collecting 4-20mA/0-10VDC signals from sensors
-
CC-TAOX01: 4-loop analog output module for driving actuators with 4-20mA/0-10VDC signals
-
CC-TDIX01: 4-loop digital input module for monitoring 24VDC discrete signals from field devices
-
CC-TDOX01: 4-loop digital output module for controlling relays and indicators with 24VDC signals
-
CC-TDIL01: Digital input module for discrete signal acquisition in industrial processes
-
CC-PDIL01: 32-channel digital I/O module for comprehensive discrete signal control
-
CC-PCNT01: High-precision pulse counting module for frequency and speed measurement
-
CC-PAIH01: Analog input module supporting HART protocol for intelligent sensor integration
-
CC-PAOX01: Analog output module for stable control signal output to actuators
-
TC-IDD321: 32-channel digital input module for high-density signal collection
-
CC-TPOX01: Interface module for reliable signal transmission in DCS systems
-
CC-IP0101: Communication interface module for Experion PKS system data exchange
-
MC-PDIY22: 32-channel digital input module for large-scale discrete signal collection
-
MC-PDOY22: 32-channel digital output module for driving multiple field devices simultaneously
-
CC-PFB401: Functional module for enhancing DCS system expansion capability
-
900ES3-0100: Digital signal processing module specialized in switching signal detection and conversion
-
900ES3-0200: Relay output signal module for driving field executive components
-
900ES4-0100: Networked signal processing module with Ethernet interface for remote data transmission
-
900ES4-0200: Redundant signal processing module ensuring uninterrupted operation for critical applications
-
900ES5-0100: Temperature signal processing module dedicated to RTD/thermocouple sensor signal conversion
-
900ES5-0200: Pressure signal conditioning module for high-precision pressure sensor data acquisition
-
900ES6-0100: Signal splitter module for distributing one input signal to multiple output channels
-
900ES6-0200: Signal isolation amplifier module with enhanced isolation voltage for high-noise environments
