Introduction to HONEYWELL CC-TDIL01
CC-TDIL01 Product Overview
The HONEYWELL CC-TDIL01 is a high-performance digital input module designed for industrial automation and distributed control systems (DCS). It serves as a critical interface component, responsible for collecting and processing discrete digital signals from field devices such as sensors, switches, and contactors, then transmitting the standardized signals to the central control unit. With its robust anti-interference design and reliable signal processing capability, this module ensures accurate data acquisition even in harsh industrial environments with strong electromagnetic interference. It is widely applied in petrochemical, power generation, and manufacturing industries, seamlessly integrating with Honeywell’s DCS platforms to enhance the stability and efficiency of process control systems.
CC-TDIL01 Technical Specifications
-
Product Model: CC-TDIL01
-
Product Type: Digital Input Module
-
Core Functions: Discrete digital signal acquisition, signal filtering and conditioning, input status monitoring, fault diagnosis and alarm, data transmission to central controller
-
Input Specifications: Number of channels: 8 channels; Input type: Dry contact (NO/NC, configurable); Input voltage: 24V DC; Response time: ≤1ms
-
Signal Processing: Built-in signal filtering circuit; Input status debounce time: 10ms – 100ms (configurable); Supports open/short circuit detection
-
Power Supply: Operating voltage: 24V DC ±10%; Power consumption: ≤5W
-
Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Relative humidity: 5% – 95% (non-condensing); Protection rating: IP20 (for module itself)
-
Mechanical & Installation: Mounting type: DIN rail mounting; Dimensions (L×W×H): 120mm × 80mm × 60mm; Net weight: 0.3kg; Enclosure material: Flame-retardant plastic
-
Certifications: CE, UL compliant; Meets IEC 61131-2 industrial control equipment standards
-
Compatibility: Seamlessly integrates with Honeywell TDC 3000, PKS series DCS; Supports Modbus RTU communication protocol
-
Applications: Industrial automation systems, distributed control systems (DCS), petrochemical plants, power generation facilities, manufacturing production lines, process control cabinets
