Introduction to HONEYWELL CC-TDOB11 (51308373-175)
CC-TDOB11 51308373-175 Product Overview
The HONEYWELL CC-TDOB11 (Product No.: 51308373-175) is a high-reliability digital output module from the CC series, specifically engineered for industrial control systems. It serves as a critical interface between Honeywell DCS controllers and field executive devices such as contactors, solenoid valves, and indicator lights, converting digital control signals from the controller into stable switching signals to drive on-site equipment. Equipped with robust electrical isolation and anti-interference technology, the module ensures reliable operation even in harsh industrial environments with strong electromagnetic interference and voltage fluctuations. Its compact, standardized 35mm DIN rail-mount design enables seamless integration into existing Honeywell control architectures, simplifying installation and on-site maintenance. Built-in self-diagnostic capabilities monitor the operational status of the module and output channels in real-time, helping maintenance teams quickly identify and resolve faults such as short circuits or overloads to minimize system downtime.
CC-TDOB11 51308373-175 Technical Specifications
-
Product Model & No.: CC-TDOB11 (51308373-175)
-
Product Type: Digital Output Module (CC Series)
-
Core Functions: Digital signal switching output; Driving field executive devices; Signal isolation & anti-interference; Real-time status monitoring; Built-in fault diagnosis & alarm (short circuit/overload)
-
Output Specifications: Output Type: Relay contact output; Number of Channels: 8 isolated channels; Contact Rating: 2A @ 250VAC / 3A @ 30VDC; Response Time: ≤5ms; Contact Life: ≥100,000 operations (at rated load)
-
Power Supply: Operating Voltage: 24VDC (±10%); Power Consumption: Typical 5W, Maximum 7W
-
Protection Features: Over-voltage protection (up to 36VDC); Per-channel short-circuit protection; 2500VAC electrical isolation between channels and power; EN 55022 Class A anti-EMI/RFI compliance
-
Environmental Limits: Operating Temperature: -30°C to +65°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 5g (10-500Hz)
-
Mechanical Details: Mounting Type: 35mm standard DIN rail; Protection Rating: IP20; Dimensions (L×W×H): Approx. 100mm × 75mm × 42mm; Net Weight: Approx. 0.28kg
-
Compatibility: Compatible with Honeywell Experion PKS, C200/C300 controllers; Complies with IEC 61131-2, IEC 61010-1 standards; CE, UL, RoHS Certified
