Introduction to HONEYWELL CC-TUIO31
CC-TUIO31 Product Overview
The HONEYWELL CC-TUIO31 is a high-reliability universal input/output (I/O) module belonging to the TDC 3000 series, specifically engineered for industrial distributed control systems (DCS). As a critical interface component between field devices and upper-level control systems, it specializes in collecting analog and digital signals from sensors, transmitters, and other field equipment, while also outputting control signals to drive actuators, valves, and relays. This module features a modular design that supports easy expansion and maintenance, making it adaptable to diverse industrial automation scenarios. Equipped with advanced signal conditioning technology, it ensures high-precision signal conversion and strong anti-interference capabilities, enabling stable operation in harsh industrial environments with electromagnetic interference, dust, and temperature fluctuations—common in petroleum, chemical, power generation, and manufacturing industries. It seamlessly integrates with Honeywell TDC 3000 DCS and compatible controllers, providing real-time data transmission and reliable control execution.
CC-TUIO31 Technical Specifications
-
Product Model: CC-TUIO31
-
Product Type: Universal Input/Output (I/O) Module (Honeywell TDC 3000 Series)
-
Core Functions: Analog/digital signal collection and conversion; Control signal output; Signal conditioning and filtering; Real-time data transmission; Built-in self-diagnosis; Overload and short-circuit protection
-
Signal & Connection: Input Signal: 4-20mA, 0-10VDC (analog); 24VDC (digital); Output Signal: 4-20mA, 0-10VDC (analog); Relay contact (digital); Communication Interface: Compatible with Honeywell TDC 3000 data highway; Connection Type: Screw terminals
-
Electrical Specifications: Operating Voltage: 24VDC; Power Consumption: Maximum 15W; Input Impedance: ≥1MΩ (analog); Output Load: 0-500Ω (analog); Measurement Accuracy: ±0.1% of full scale
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP20 (when installed in standard control cabinet)
-
Mechanical Details: Housing Material: Industrial-grade plastic; Net Weight: Approx. 0.8kg; Mounting Type: DIN rail or rack mounting; Dimensions (L×W×H): 160mm × 100mm × 45mm
-
System Compatibility: Fully compatible with Honeywell TDC 3000 DCS; Suitable for integration into petroleum, chemical, power generation, and manufacturing industry control setups
Recommended HONEYWELL Similar Series Models
-
CC-TAOX11: Analog output module specialized in 4-20mA signal output for actuator control
-
CC-TAIH11: High-precision analog input module with HART protocol support for intelligent sensors
-
CC-TDIL11: Digital input module for 24VDC discrete signal collection
-
CC-TUIO32: Enhanced universal I/O module with expanded channel capacity
-
CC-TCIL01: Thermocouple input module for temperature signal collection and conversion
-
CC-TRIO01: RTD input module dedicated to resistance temperature detector signal processing
-
CC-TMIO01: Mixed I/O module combining analog and digital channels for flexible configuration
-
CC-TCOMM01: Communication interface module for TDC 3000 system data transmission
-
CC-TPWR01: Power supply module providing stable voltage for TDC 3000 series I/O modules
-
CC-TRED01: Redundant I/O module for critical control applications ensuring uninterrupted operation
-
CC-TAOX12: Multi-channel analog output module for simultaneous control of multiple actuators
-
900ES3-0100: Digital signal processing module specialized in switching signal detection and conversion
-
900ES3-0200: Relay output signal module for driving field executive components
-
900ES4-0100: Networked signal processing module with Ethernet interface for remote data transmission
-
900ES4-0200: Redundant signal processing module ensuring uninterrupted operation for critical applications
-
900ES5-0100: Temperature signal processing module dedicated to RTD/thermocouple sensor signal conversion
-
900ES5-0200: Pressure signal conditioning module for high-precision pressure sensor data acquisition
-
900ES6-0100: Signal splitter module for distributing one input signal to multiple output channels
-
900ES6-0200: Signal isolation amplifier module with enhanced isolation voltage for high-noise environments
