Introduction to HONEYWELL FC-PSU-UNI2450U
FC-PSU-UNI2450U Product Overview
The HONEYWELL FC-PSU-UNI2450U is a UL 508-approved switched-mode DC power supply unit, tailored for high reliability and efficiency in industrial automation and safety instrumented systems (SIS). It serves as a core power component that converts a wide range of AC input into stable DC output, delivering continuous and reliable power to critical field devices such as sensors, actuators, and controllers. Equipped with dual over-voltage protection, overload protection, and a fan status monitoring system, this unit ensures stable operation even in harsh industrial environments. It also supports parallel operation for redundancy and features isolated AC/DC connectors for online replacement, seamlessly integrating with Honeywell DCS systems (e.g., PKS, C300) to safeguard the continuity and safety of critical industrial processes.
FC-PSU-UNI2450U Technical Specifications
-
Product Model: FC-PSU-UNI2450U
-
Product Type: Industrial Switched-Mode DC Power Supply Unit
-
Core Functions: AC-DC power conversion, stable DC power supply, dual over-voltage protection, overload/short-circuit protection, under-voltage alarm, fan status monitoring, parallel operation support
-
Input Parameters: AC input voltage: 100-240V AC (operating limits: 93-253V AC); Input frequency: 47-63Hz; No-load power consumption: 13W; Power factor: Close to 1
-
Output Parameters: DC output voltage: 25V DC or 28V DC (dual options); Output current: 48A (25V DC) / 43A (28V DC) at -5°C to +50°C; Ripple & noise: <40mVpp; Maximum output power: 1200W; Hold-up time: 100ms
-
Efficiency & Protection: Conversion efficiency: >85% at 220-240V AC, >80% at 110-120V AC; Protection mechanisms: Dual over-voltage protection, overload protection, short-circuit protection, over-temperature protection
-
Environmental Ratings: Operating temperature: -5°C to +70°C; Storage temperature: -25°C to +85°C; Relative humidity: 5% – 95% (non-condensing)
-
Mechanical & Installation: Mounting type: Standard industrial mounting; Dimensions (L×W×H): 420.5mm × 140mm × 90mm; Net weight: 5.7kg; Connectors: IEC 60320 C20 AC input socket, Phoenix PCV DC output connector
-
Certifications: UL 508, EN 61558-2-16 compliant; Meets IEC 61508 functional safety requirements
-
Compatibility: Seamlessly integrates with Honeywell DCS systems (PKS, C300); Supports parallel operation for redundancy; Compatible with various industrial control and safety instrumented systems
-
Applications: Industrial automation systems, safety instrumented systems (SIS), petrochemical plants, power generation facilities, fire alarm systems, security monitoring systems, and other critical process control scenarios
Recommended HONEYWELL Same-Series Models
-
HONEYWELL FA-PSU-UNI2450U: Hazardous area certified (ATEX, IECEx, CSA), operating temperature down to -40°C for extreme harsh environments
-
HONEYWELL FC-PSU-UNI4825U: 48V DC output with 25A current capacity, tailored for high-voltage industrial equipment
-
HONEYWELL FC-PSU-UNI6020U: 60V DC output, 20A current rating, suitable for specific high-voltage control systems
-
HONEYWELL FC-PSU-UNI11011U: 110V DC output, 11A current capacity, designed for large-scale industrial automation systems
-
HONEYWELL FC-PSU-UNI2450U V2.1: Enhanced version with dual redundant output cards and 8 safety-related output channels, ensuring uninterrupted power supply upon single card failure
-
HONEYWELL FC-PSU-240516 V1.1: Compact power supply module with 24V DC output, ideal for space-constrained installation scenarios
-
HONEYWELL FCPS-24: Compact remote power supply with integrated battery charger, offering 6/8A current options for small-scale systems
-
HONEYWELL PS Series 10A: Remote power supply with battery charger and 7 independently configurable outputs, enabling flexible power distribution
-
HONEYWELL HLSP-DB2: Dual-output power supply unit, providing redundant power support for critical safety systems
-
HONEYWELL 45Ah Power Supply/Charger Unit: High-capacity battery charger integrated power supply, suitable for backup power systems requiring long-term standby
-
HONEYWELL FC-PSU-UNI24100U: 24V DC output with 100A high current capacity, designed for large-scale industrial equipment clusters
-
HONEYWELL FA-PSU-UNI4825U: Hazardous area-compliant 48V DC power supply with 25A current, suitable for explosive environment applications
