Introduction to HONEYWELL FTA-T-02
FTA-T-02 Product Introduction
The HONEYWELL FTA-T-02 is a high-reliability fail-safe digital output module, specifically engineered for industrial automation systems to ensure safe and stable control signal transmission. As a critical interface component between central control units and field actuators, it is designed to reliably output control signals to external equipment, playing a key role in safeguarding the safety and stability of industrial production processes. Equipped with 24 output channels grouped into 6 sets of 4, this module can simultaneously control multiple devices, enhancing operational efficiency in complex industrial scenarios. It features a built-in diagnostic system that enables real-time fault detection, simplifying maintenance procedures and reducing downtime. With a rugged industrial-grade design, it can operate stably in harsh environments with temperature fluctuations and high humidity.
FTA-T-02 Technical Parameters
-
Product Model: FTA-T-02
-
Product Type: Fail-Safe Digital Output Module (Honeywell FTA Series)
-
Core Functions: Reliable control signal output; 24-channel grouped control (6 sets of 4); Real-time fault diagnosis; Fail-safe protection for industrial processes; Multiple device simultaneous control
-
Connection Specifications: Screw terminal connections; Maximum wire size: 0.25 cm² (AWG 14); Wire stripping length: 0.7 cm; Tightening torque: 0.5 Nm; Compatible with mainstream industrial control systems
-
Electrical Specifications: Power Supply: Compatible with 24/48/60 Vdc; Maximum Voltage: 36 Vac / 50 Vdc (IEC 1010 Overvoltage Category 3), 125 Vac / 150 Vdc (IEC 1010 Overvoltage Category 2); Maximum Continuous Current per Channel: 2A; Certifications: CE, UL, CSA compliant
-
Environmental Ratings: Operating Temperature: -25°C to 70°C; Storage Temperature: -40°C to 85°C; Relative Humidity: 5% – 95% (non-condensing)
-
Mechanical Details: Housing Material: Industrial-grade high-strength material; Dimensions: Approximately 14.5 cm × 7 cm × 5.7 cm; Weight: Approximately 0.44 lbs (0.2 kg); Installation: DIN rail mounting
-
System Compatibility: Fully compatible with Honeywell industrial DCS and PLC systems; Suitable for integration into petrochemical, power generation, and manufacturing industry control setups
Recommended Honeywell Same-Series Models
-
FTA-T-01: FTA series fail-safe digital output module with 16 channels
-
FTA-T-03: FTA series fail-safe digital output module with 32 channels
-
FTA-A-02: FTA series analog input module for high-precision signal acquisition
-
FTA-A-04: FTA series analog output module for reliable control signal transmission
-
FTA-D-02: FTA series digital input module for discrete signal collection
-
FTA-S-01: FTA series safety monitoring module for real-time system status supervision
-
FC-TSAI-1620M: 16-channel high-precision safety analog input module
-
FC-SDO-0824: 8-channel fail-safe digital output module for safety-critical applications
-
FC-SPWR-2405: 24VDC redundant power supply module for system power protection
-
FC-SCOM-01: Communication module for data exchange between DCS and upper-level systems
-
FC-SDIAG-01: System diagnostic module for real-time fault monitoring and alarm
-
FC-IOCHAS-0002S: I/O chassis module for system expansion
-
FC-TDILA1: Digital input module for discrete signal collection
-
FC-TDODA1: Digital output module for driving field switching devices
-
FTA-R-01: FTA series relay output module for high-load device control
-
FTA-C-01: FTA series communication extension module for long-distance signal transmission
-
FTA-P-01: FTA series power supply module dedicated to FTA series modules
-
FC-QPP-0001: Quad-core processor module for core computing in safety systems
-
FC-RUSIO-3224: 32-input 24-output remote universal safety I/O module
-
FC-USI-0002: Universal safety interface module for connecting safety devices to controllers
