Introduction to HONEYWELL M9494F1003
M9494F1003 Product Overview
The HONEYWELL M9494F1003 is a high-performance electric actuator from the M9494 series, designed for precise control of valves and dampers in HVAC and industrial process systems. It converts electrical signals into accurate mechanical motion to stabilize valve opening adjustments, featuring a robust gear train and high-torque motor for reliable long-term operation. With intelligent control circuits, it supports multiple signal types and provides real-time position feedback, enabling seamless integration with building automation and industrial control systems. Its compact design allows easy installation in limited spaces, while the IP54 protection rating ensures dust and water splash resistance for indoor and outdoor use. Overload and overheating protection further enhance operational safety by preventing damage from abnormal conditions.
M9494F1003 Technical Specifications
-
Product Model: M9494F1003
-
Product Type: Electric Actuator (Honeywell M9494 Series)
-
Core Functions: Precise valve/damper position control; Multiple control signal compatibility; Real-time position feedback; Overload and overheating protection; Manual operation mode (for maintenance); Continuous duty operation
-
Signal & Connection: Control Signal: 0-10VDC, 4-20mA; Feedback Signal: 0-10VDC; Communication Interface: Optional MODBUS RTU; Connection Type: Screw terminals
-
Electrical Specifications: Operating Voltage: 24VAC/DC; Power Consumption: 40VA (max); Torque Output: 40 N·m; Stroke: 90° (rotational); Response Time: ≤15 seconds (full stroke)
-
Environmental Ratings: Operating Temperature: -20°C to +60°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP54
-
Mechanical Details: Housing Material: Die-cast aluminum; Net Weight: Approx. 2.8kg; Mounting Type: Direct flange mounting; Gear Type: Precision worm gear
-
System Compatibility: Compatible with Honeywell building automation systems and mainstream industrial control systems; Suitable for HVAC systems, industrial process control, power plants, and chemical industry valve/damper control setups
Recommended HONEYWELL Similar Series Models
-
M9494D1004: Compact 20 N·m torque actuator for small valves/dampers
-
M9494E1005: 30 N·m medium-torque actuator with improved position accuracy
-
M9494G1006: 60 N·m high-torque actuator for heavy-duty industrial valve control
-
M9494H1007: Explosion-proof actuator for hazardous area applications
-
M9494J1008: Smart actuator with built-in LCD for on-site parameter setting
-
M9494K1009: Actuator with battery backup for emergency position retention
-
M9494L1010: Low-temperature resistant actuator (-40°C to +60°C) for cold environments
-
M9494M1011: Multi-turn actuator for linear valve control in water treatment
-
M9494N1012: Network-enabled actuator with BACnet for smart building integration
-
M9494P1013: Double-acting actuator for bidirectional valve/damper control
-
M9494Q1014: Corrosion-resistant actuator for chemical industry applications
-
M9494R1015: High-speed response actuator (≤10s full stroke) for real-time control
-
900ES3-0100: Digital signal processing module specialized in switching signal detection and conversion
-
900ES3-0200: Relay output signal module for driving field executive components
-
900ES4-0100: Networked signal processing module with Ethernet interface for remote data transmission
-
900ES4-0200: Redundant signal processing module ensuring uninterrupted operation for critical applications
-
900ES5-0100: Temperature signal processing module dedicated to RTD/thermocouple sensor signal conversion
-
900ES5-0200: Pressure signal conditioning module for high-precision pressure sensor data acquisition
-
900ES6-0100: Signal splitter module for distributing one input signal to multiple output channels
-
900ES6-0200: Signal isolation amplifier module with enhanced isolation voltage for high-noise environments
