Introduction to HONEYWELL SAI-1620M
SAI-1620M Product Overview
The HONEYWELL SAI-1620M is a high-performance 16-channel analog input module designed for industrial automation and distributed control systems (DCS). As a key component in process signal acquisition, it specializes in collecting and conditioning analog signals from a wide range of field sensors, such as temperature, pressure, and flow sensors, and transmitting the standardized signals to the central controller. This module features high input accuracy and excellent anti-interference performance, ensuring stable and reliable data transmission even in harsh industrial environments with strong electromagnetic interference and voltage fluctuations. Its modular and compact design allows for easy installation on standard DIN rails or system backplanes, facilitating system expansion and maintenance. Widely applied in petrochemical, power generation, metallurgy, and other process industries, the SAI-1620M provides critical support for real-time monitoring and precise control of industrial processes, helping to improve production efficiency and operational safety.
SAI-1620M Technical Specifications
-
Product Model: SAI-1620M
-
Product Type: 16-channel Analog Input Module (Industrial Automation Series)
-
Core Functions: 16-channel analog signal acquisition and conditioning; High-precision signal conversion; Anti-interference processing for industrial environment; Real-time signal monitoring and fault indication; Support for hot-swapping (optional)
-
Input Specifications: Channel Quantity: 16 single-ended or 8 differential channels; Signal Type: 4-20mA DC current signal, 0-10V DC voltage signal; Input Range: 0-22mA (current), 0-12V (voltage); Accuracy: ±0.1% of full scale; Sampling Rate: Up to 50 samples per second per channel
-
Conversion Performance: Resolution: 16-bit; Linear Error: ≤±0.05% FS; Response Time: ≤10ms
-
Power Supply: Operating Voltage: 24VDC (redundant power optional); Power Consumption: Typical 12W, Maximum 15W
-
Protection Features: Over-voltage protection (up to 36VDC); Short-circuit protection; Anti-electromagnetic interference (EMI) design; Electrical isolation (2500VAC) between channels and system
-
Environmental Limits: Operating Temperature: -40°C to +70°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 10g (10-500Hz)
-
Mechanical Details: Mounting Type: DIN rail mounting (35mm standard rail) or backplane mounting; Protection Rating: IP20; Dimensions (L×W×H): Approx. 160mm × 110mm × 35mm; Net Weight: Approx. 0.8kg
-
Compatibility & Certifications: Seamless integration with Honeywell industrial automation systems and DCS; Complies with IEC 61131-2 and IEC 61010-1 standards; CE, UL and RoHS Compliant
Recommended Honeywell Same-Series Models
-
HONEYWELL SAI-810M: 8-channel analog input module for basic process signal acquisition
-
HONEYWELL SAO-1620M: 16-channel analog output module for stable 4-20mA/0-10V control signal transmission
-
HONEYWELL SAI-1621M: Enhanced 16-channel analog input module with HART communication function
-
HONEYWELL SDI-3210M: 32-channel digital input module for large-scale switching signal collection
-
HONEYWELL SDO-1610M: 16-channel digital output module for control signal output to field actuators
-
HONEYWELL SAI-430M: 4-channel high-precision analog input module for special sensor signal acquisition
-
HONEYWELL SAO-820M: 8-channel analog output module with enhanced load capacity
-
HONEYWELL SAI-1622M: 16-channel analog input module with built-in signal isolation and surge protection
-
HONEYWELL SDI-1610M: 16-channel digital input module with high anti-interference capability
-
HONEYWELL SDO-3210M: 32-channel digital output module for heavy-load field device control
-
HONEYWELL SAI-820M: 8-channel analog input module with diagnostic function for real-time signal status monitoring
-
HONEYWELL SAO-410M: 4-channel precision analog output module for high-accuracy control scenarios
-
HONEYWELL SAI-1610M: Economic 16-channel analog input module for cost-sensitive applications
-
HONEYWELL SDI-810M: 8-channel compact digital input module for limited space installation
-
HONEYWELL SDO-810M: 8-channel compact digital output module for small-scale control systems
