Introduction to HONEYWELL SC-PCMX01 51307195-175
SC-PCMX01 51307195-175 Product Introduction
The HONEYWELL SC-PCMX01 51307195-175 is a high-performance process control module belonging to the SC series, specifically engineered for industrial automation and PLC/DCS control systems. As a core component in process monitoring and control loops, it is designed to collect, process, and transmit critical process data, enabling precise regulation of industrial processes such as temperature, pressure, flow, and level. This module supports multiple industry-standard communication protocols including Modbus RTU and DNP3, ensuring seamless data exchange with upper-level controllers and remote terminal units (RTUs), thus facilitating flexible system integration and centralized monitoring. Equipped with isolated input/output channels, it effectively resists electromagnetic interference in harsh industrial environments, guaranteeing the accuracy and reliability of data transmission. Adopting a modular and compact DIN rail mounting design, it allows for easy installation, maintenance, and hot-swappable replacement, significantly reducing system downtime.
SC-PCMX01 51307195-175 Technical Specifications
-
Product Model: SC-PCMX01 51307195-175
-
Product Type: Process Control Module (Honeywell SC Series)
-
Core Functions: Industrial process data collection and processing; Precise process parameter regulation; Multi-protocol communication support; Isolated signal transmission; Hot-swappable maintenance
-
Signal & Connection: Input/Output Channels: Isolated channels (quantity matching SC series standard configuration); Communication Protocols: Modbus RTU, DNP3; Connection Mode: DIN rail mounting
-
Electrical Specifications: Operating Voltage: 24VDC; Loop Power Supply: Isolated 24VDC±5% regulated, max 30mA; Maximum Power Consumption: 9W (typical 7.8W); Input Current: 2A (max)
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP20
-
Mechanical Details: Housing Material: Industrial-grade anti-corrosion plastic; Mounting Type: DIN rail; Dimensions: 105mm × 55mm × 32mm; Net Weight: Approx. 0.6kg
-
System Compatibility: Fully compatible with Honeywell PLC/DCS systems and SC series RTUs; Suitable for integration into petroleum, chemical, power generation, water treatment, and building automation industry control setups
Recommended Honeywell Models
-
SC-TCMX01 51307198-175: SC series digital output module with 8 channels, supporting relay/transistor drive types
-
SC-UCMX01 51307198-175: SC series RTU/controller module with energy management and remote monitoring functions
-
SC-UCMX02 51307198-276: SC series RTU module with 24 digital input and 16 digital output points, supporting Modbus/DNP3 protocols
-
SC500 Series Signal Conditioner: SC series sensor signal conditioning module with automatic calibration function
-
SC-PCMX02 51307195-275: SC series process control module with extended channel capacity and enhanced data processing capability
-
CC-PAIH01: Analog input module with HART protocol for intelligent sensor data collection
-
CC-PAOX01: Analog output module for stable actuator control signal transmission
-
51305072-200: CLCN series communication module for LCN network connection
-
TC-CCR014: Redundant network interface module ensuring continuous system communication
-
51196655-100 ACX633: ACX series power supply module for stable system power supply
-
CC-PWRR01: 20A redundant DC power module for cabinet-level power supply protection
-
CC-PCNT01: C300 control processor module for core industrial process control
-
TC-FTEB01: FTE bridge module for C300 system network redundancy
-
CC-PDIS01: Digital input module with SOE function for event sequence recording
