Introduction to HONEYWELL SC-UCMX01 51307195-175
SC-UCMX01 51307195-175 Product Overview
The HONEYWELL SC-UCMX01 (Part Number: 51307195-175) is a high-performance universal control module designed for Honeywell SC-series industrial automation systems. As a core communication and control intermediate component, it excels in enhancing system connectivity by enabling seamless data exchange and precise control signal transmission between main controllers and on-site I/O devices. This module supports multiple industrial communication protocols including Modbus and Profibus, allowing flexible integration with a wide range of sensors, actuators, and sub-controllers. Equipped with robust anti-electromagnetic interference design and lightning protection features, it ensures stable and reliable operation in harsh industrial environments. Its modular structure facilitates easy installation, configuration, and maintenance, while the built-in self-diagnostic function enables timely fault detection and alarm. Widely applied in process control, building automation, water treatment, and energy management fields, it provides solid support for complex control tasks and improves the overall operational efficiency and stability of automation systems.
SC-UCMX01 51307195-175 Technical Specifications
-
Product Model & Part Number: SC-UCMX01 (51307195-175)
-
Product Type: Universal Control Module (SC-series Compact Control Module Series)
-
Core Functions: Enhance system communication capability; Facilitate data exchange between controller and I/O devices; Transmit precise control signals; Support multi-protocol communication; Enable remote monitoring and maintenance; Provide self-diagnostic and fault alarm functions
-
Communication Specifications: Supported Protocols: Modbus, Profibus; Communication Interfaces: RS-232, RS-485, Ethernet port, CAN bus interface; Data Transmission Rate: Up to 100 Mbps (Ethernet)
-
Input/Output Specifications: Digital Input: Up to 96 channels; Analog Input: Up to 32 channels; Digital Output: Configurable; Analog Output: Configurable
-
Power Supply: Operating Voltage: 24VDC; Power Consumption: Typical 8W, Maximum 12W
-
Protection Features: Over-voltage protection; Short-circuit protection; Reverse polarity protection; Anti-electromagnetic interference design; Lightning protection
-
Environmental Limits: Operating Temperature: -20°C to +60°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing)
-
Mechanical Details: Mounting Type: DIN rail mounting; Protection Rating: IP20; Dimensions (L×W×H): Approx. 100mm × 70mm × 25mm; Net Weight: Approx. 0.5kg
-
Compatibility & Certifications: Seamless integration with Honeywell SC-series controllers and I/O modules; Complies with IEC 61131-3 standard; CE, UL and RoHS Compliant
