Introduction to HONEYWELL SC-UCMX01 51307198-175
SC-UCMX01 51307198-175 Product Overview
The HONEYWELL SC-UCMX01 (Part Number: 51307198-175) is a high-reliability universal control module tailored for Honeywell SC-series industrial automation systems. As a key intermediate component, it enhances system communication capabilities by enabling seamless data exchange and precise control signal transmission between main controllers and on-site I/O devices. Supporting multiple communication protocols such as Modbus, this module allows flexible integration with various sensors, actuators, and sub-controllers. Its robust hardware design ensures stable operation in harsh industrial environments with electromagnetic interference, while the modular structure simplifies installation, configuration, and maintenance. Widely applicable in process control, building automation, and water treatment fields, it provides reliable support for complex control tasks and improves overall system operational efficiency.
SC-UCMX01 51307198-175 Technical Specifications
-
Product Model & Part Number: SC-UCMX01 (51307198-175)
-
Product Type: Universal Control Module (SC-series Automation Series)
-
Core Functions: Enhance system communication capability; Facilitate data exchange between controller and I/O devices; Transmit precise control signals; Support multi-protocol communication; Enable remote monitoring and maintenance
-
Communication Specifications: Supported Protocols: Modbus; Communication Interfaces: Multiple serial ports, Ethernet port; Data Transmission Rate: Up to 100 Mbps (Ethernet)
-
Input/Output Specifications: Digital Input: Up to 96 channels; Analog Input: Up to 32 channels; Digital Output: Configurable; Analog Output: Configurable
-
Power Supply: Operating Voltage: 24VDC ±10%; Power Consumption: Typical 8W, Maximum 12W
-
Protection Features: Over-voltage protection; Short-circuit protection; Reverse polarity protection; Anti-electromagnetic interference design
-
Environmental Limits: Operating Temperature: -20°C to +60°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing)
-
Mechanical Details: Mounting Type: DIN rail mounting; Protection Rating: IP20; Net Weight: Approx. 0.5kg
-
Compatibility & Certifications: Seamless integration with Honeywell SC-series controllers and I/O modules; RoHS Compliant
Recommended Honeywell Same-Series Models
-
HONEYWELL SC-TCMX01 51307198-175: Digital output module for converting digital signals to physical outputs to control valves and motors
-
HONEYWELL SC-UIO01: Universal I/O module for expanding digital and analog I/O channels
-
HONEYWELL SC-UCMX02: Enhanced universal control module with extended communication protocols
-
HONEYWELL SC-PWR01: 24VDC power supply module for SC-series control components
-
HONEYWELL SC-NET01: Network communication module for SC-series system networking
-
HONEYWELL SC-TEMP01: Temperature monitoring module for HVAC and industrial temperature control
-
HONEYWELL SC-HVAC01: Specialized control module for heating, ventilation and air conditioning systems
-
HONEYWELL SC-ALM01: Alarm monitoring module for real-time fault alarm and notification
-
HONEYWELL SC-LINK01: Protocol conversion module for integrating third-party standard devices
-
HONEYWELL 51307199-100: SC-series redundant control module for high-reliability applications
-
HONEYWELL 51307200-200: SC-series digital I/O expansion module with 16 input/output channels
-
HONEYWELL SC-CPU01: Core controller module for SC-series automation system
-
HONEYWELL SC500: Sensor signal conditioning module with automatic calibration function
