Introduction to HONEYWELL TC-CCN014
TC-CCN014 Product Overview
The HONEYWELL TC-CCN014 is a high-reliability redundant network interface module specifically engineered for Honeywell C200 series distributed control systems (DCS). As a core communication component in industrial automation architectures, it is designed to provide dual independent network connections, ensuring uninterrupted data transmission even when a single network link fails. This module supports a variety of mainstream industrial communication protocols, including Modbus, EtherNet/IP, and Profibus, enabling seamless data exchange and interoperability with PLCs, HMIs, sensors, and other field devices. Its robust industrial-grade design, featuring an IP67 protection rating, equips it with excellent resistance to harsh environmental conditions such as high temperature, humidity, dust, and electromagnetic interference—common in manufacturing, energy, petroleum, and natural gas industries. With a user-friendly plug-and-play design, the TC-CCN014 simplifies installation and maintenance processes, while integrated real-time monitoring and diagnostic functions allow for timely detection of network faults and issuance of alarms.
TC-CCN014 Technical Specifications
-
Product Model: TC-CCN014
-
Product Type: Redundant Network Interface Module (Honeywell C200 Series Compatible)
-
Core Functions: Dual redundant network connection; Multi-protocol data transmission; Real-time network status monitoring; Fault diagnosis and alarm; Uninterrupted communication guarantee; Overload and short-circuit protection
-
Signal & Connection: Supported Protocols: Modbus, EtherNet/IP, Profibus, CAN; Network Interfaces: 2 x RJ-45 ports; Additional Interfaces: RS232/RS485; I/O Points: 8 digital inputs/outputs, 4 analog inputs/2 analog outputs
-
Electrical Specifications: Operating Voltage: 24VDC; Output Voltage: 0~10VDC; Power Consumption: Less than 5W; Anti-RF Interference: Error ≤ 2.0% of range at 10V/m, 27~1000MHz
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP67
-
Mechanical Details: Dimensions (L×W×H): 144mm × 96mm × 22mm; Net Weight: Approx. 0.5kg; Housing Material: ABS plastic; Mounting Type: Plug-in installation
-
System Compatibility: Fully compatible with Honeywell C200 series DCS and controllers; Suitable for industrial control, building automation, power systems, and petroleum & natural gas industry setups
Recommended HONEYWELL Similar Series Models
-
TC-FXX102: Digital input/output module for industrial process signal acquisition and control
-
TC-FFB01: Safety relay module with redundant protection for critical control scenarios
-
MC-TAMR03: Analog input module for precise process parameter collection in C200 systems
-
MC-TLPA02: Power supply module providing stable voltage output for TC series modules
-
MU-TAMR02: Redundant analog input module enhancing system reliability
-
TC-FPDXX2: High-speed digital signal processing module for real-time monitoring
-
TK-CCR014: Communication control module supporting multi-protocol conversion
-
TK-PRR021: Redundant power supply module ensuring continuous system operation
-
MC-TAIH12: HART-enabled analog input module for intelligent sensor integration
-
MC-TDIY22: Isolated digital input module with strong anti-interference capability
-
MC-PAIH03: High-precision analog input module compatible with C200 DCS
-
MC-PAOY22: Analog output module for driving field actuators with precise control
-
TK-IOLI01: Integrated I/O module for mixed signal processing in industrial automation
-
GN-KRR011: Safety monitoring module for TC series system fault prevention
