Introduction to HONEYWELL TC-PPD011
TC-PPD011 Product Overview
The HONEYWELL TC-PPD011 is a versatile and high-reliability analog input module, specifically designed for Honeywell industrial automation and control systems. As a key data acquisition component, it excels in receiving and processing various analog signals from field devices, such as temperature, pressure, and flow sensors, then converting these signals into digital formats compatible with PLCs and DCS controllers. Beyond analog signal handling, it also integrates digital input and pulse input functionalities, capable of collecting dry contact, active contact switch signals, and dry contact pulse signals—making it suitable for applications like pulse water meter data collection. Equipped with robust signal processing capabilities and support for protocols such as UDP and TCP, it ensures timely and accurate multi-center data communication. The module features a compact, industrial-grade design with a wide operating temperature range, enabling stable performance in harsh industrial environments.
TC-PPD011 Technical Specifications
-
Product Model: TC-PPD011
-
Product Type: Analog Input Module (Honeywell Industrial Automation Series)
-
Core Functions: Analog signal acquisition and conversion; Digital and pulse signal input; Multi-protocol data communication; Signal conditioning and filtering; Configurable via DIP switches; Energy-saving timed data collection
-
Input Specifications: Supported Analog Signals: 4-20mA current, 0-5V voltage; Digital Input: Dry contact, active contact signals; Pulse Input: Dry contact pulse signals
-
Communication Parameters: Supported Protocols: UDP, TCP; Communication Type: Multi-center data communication
-
Power Supply: Input Voltage: 5VDC; Output Voltage: 3.3VDC; Power Consumption: Low power design
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing)
-
Mechanical Details: Dimensions (L×W×H): Approx. 25mm × 25mm × 5mm; Housing Options: Black, gray; Terminal Type: Standard industrial terminals; Indicators: Configurable LED status indicators
-
Product Features: High reliability and stability; Wide operating temperature range; Easy configuration and installation; Multiple signal type support; Energy-saving operation mode
Recommended HONEYWELL Similar Series Models
-
TK-PPD011: Compatible analog input module with enhanced anti-interference capability
-
TC-IAH161: 16-channel high-level analog input module
-
TC-IDD321: 32-channel digital input module with high-density design
-
TC-ODD321: 32-channel digital output module with short-circuit protection
-
TC-PRS021: Power supply monitoring module for TC series I/O systems
-
TC-PRR021: Redundant power supply module for critical control systems
-
TC-IOLI01: I/O link isolation module compatible with TC series
-
TC-FPDXX2: High-speed Ethernet communication module for data transmission
-
TC-FTEB01: Fault-tolerant Ethernet bridge module
-
TC-CCR014: Redundant network interface module for distributed control systems
-
TC-OAH061: 6-channel analog output module for field device control
-
TC-IDJ161: 16-channel digital input module with flexible configuration
-
TC-IXR061: 6-channel digital input module with extended temperature range
-
TC-OAV081: 8-channel analog output module with voltage signal support
