Introduction to HONEYWELL TK-FTEB01
TK-FTEB01 Product Overview
The HONEYWELL TK-FTEB01 is a high-reliability FTE (Fault-Tolerant Ethernet) Bridge Module, specifically engineered for Honeywell distributed control systems (DCS). It serves as a critical network distribution component, efficiently allocating FTE cables to multiple Series C Fieldbus Interface Modules (FIMs), thereby establishing a stable and redundant communication network for on-site cabinet network nodes such as C300 controllers and C-series modules. This module is designed to be installed on the CF9 Input/Output Terminal Assembly (IOTA), featuring a compact and integrated design that facilitates seamless integration into existing Honeywell control architectures. With robust fault-tolerant capabilities, it ensures continuous and reliable data transmission even in the event of single-point network failures, significantly enhancing the overall availability and stability of the industrial control system. Suitable for petrochemical, power generation, and other process industries with high requirements for system reliability, the TK-FTEB01 provides a secure and efficient network foundation for industrial automation operations.
TK-FTEB01 Technical Specifications
-
Product Model: TK-FTEB01
-
Product Type: FTE (Fault-Tolerant Ethernet) Bridge Module
-
Core Functions: FTE cable distribution to multiple Series C FIMs; On-site cabinet network node FTE distribution; Fault-tolerant Ethernet communication support; Stable data transmission guarantee between control system components
-
Installation Compatibility: Designed for installation on CF9 Input/Output Terminal Assembly (IOTA); Compatible with Honeywell C300 controllers and C-series modules
-
Power Supply: Operating Voltage: 24VDC; Current Rating: 0.112A @ 24VDC
-
Mechanical Details: Shipping Weight: Approximately 2kg; Design: Compact integrated structure for cabinet installation
-
Environmental Limits: Operating Temperature: -40°C to +70°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing)
-
Application Scope: Suitable for Honeywell DCS distributed control systems; Widely used in petrochemical, power generation and other process industrial fields
-
Product Certification: Complies with relevant industrial control network equipment standards; Original Honeywell quality certification
Recommended HONEYWELL Similar Series Models
-
TK-FTEB02: Enhanced FTE bridge module with extended network node support
-
CC-PFB401: Series C fieldbus interface module for Foundation Fieldbus communication
-
TC-CCR014: Redundant network interface module for industrial control systems
-
TK-CCR014: Redundant network module with advanced diagnostic functions
-
CC-IP0101: Industrial Ethernet communication module for protocol conversion
-
TC-FXX102: Industrial network communication module for fieldbus integration
-
TC-FFB01: Foundation Fieldbus interface module with redundancy function
-
TK-PRR021: Redundant power supply module for TK series network modules
-
MU-TMCN02: System communication controller with redundant network interface
-
TK-IOLI01: I/O link module for redundant network architectures
-
CC-PDOB01: Ethernet communication gateway module for data acquisition and transmission
-
TC-KIOL02: Industrial I/O module with network redundancy support
-
TK-PPD011: Network performance monitoring module for TK series
-
CC-TCF901: Industrial control firewall module with network security protection
