IC800SSI216RD2-CE | GE Electric Compact I/O controller
Product Description
The GE IC800SSI216RD2-CE is a compact I/O controller from GE’s VersaMax Micro series, combining 8 digital inputs and 8 relay outputs with embedded PLC logic. Designed as a space-saving automation solution, it delivers localized control for simple machinery while enabling cloud connectivity via GE’s Edge Controls platform for remote diagnostics and IoT integration.
Key Features
- Integrated Control & I/O: 8x 24V DC inputs + 8x relay outputs (5A SPDT) with embedded logic.
- Cloud-Ready: Built-in MQTT/OPC UA protocols for GE Edge Controls.
- Modbus RTU Slave: RS-485 communication for SCADA/HMI integration.
- Tool-Free Wiring: Spring-clamp terminals for rapid installation.
- Standalone Operation: Executes logic without external CPU.
- Diagnostic Indicators: Per-channel LED status (input/output health).
Product Specifications
|
Parameter
|
Specification
|
|---|---|
|
Input Channels
|
8x 24V DC (Sink/Source, IEC 61131-2)
|
|
Input Current
|
4mA typical (per point)
|
|
Output Channels
|
8x SPDT relays (Form C)
|
|
Output Rating
|
5A @ 250V AC / 5A @ 30V DC (resistive)
|
|
Logic Memory
|
32 KB (ladder logic)
|
|
Communication
|
RS-485 (Modbus RTU, 115.2 kbps max)
|
|
Power Supply
|
24V DC (±15%)
|
|
Power Consumption
|
1.7W (typical)
|
|
Isolation
|
1500V AC (field to logic)
|
|
Operating Temperature
|
-20°C to +60°C
|
|
Certifications
|
cULus, CE, RoHS, IEC 61131-2
|
|
Software
|
GE Machine Edition Logic Developer
|
Series Overview
Part of GE VersaMax Micro Series:
- IC800SSI216RD2-CE: 8DI/8RO combo module (CE = cloud-enabled).
- IC800CPU001-CE: Micro-PLC CPU expansion option.
- IC800BEM001: I/O expansion base (supports ≤7 modules).
- IC800SSD008: 8-point digital output module (non-relay).
Applications
- Lighting Control: Streetlight sequencing & fault reporting.
- Small Conveyors: Motor start/stop and jam detection.
- HVAC Units: Damper control and thermostat interfacing.
- Vending Machines: Payment system logic and motor control.
- Security Systems: Door lock/sensor monitoring.
Functional Role
- Embedded Automation: Runs ladder logic locally for I/O devices.
- Edge Connectivity: Transfers operational data to GE Predix cloud via MQTT.
- Cost Optimization: Replaces relay panels with programmable control.
- Modbus Gateway: Interfaces sensors/actuators with SCADA systems via RS-485.
Why Choose IC800SSI216RD2-CE?
- Ultra-Compact: 45mm width (DIN-rail mount) for tight enclosures.
- Rapid Deployment: Pre-loaded application templates (e.g., timer chains).
- IoT Enabled: Real-time analytics via Edge Controls dashboard.
- Low TCO: 40% lower wiring/maintenance costs vs. discrete relays.
- Scalable: Expands via VersaMax bases (up to 64 I/O points).
Critical Notes:
- Relay outputs derate for inductive loads (2A @ 30V DC for solenoids).
- Max ambient temperature: 60°C (requires derating above 40°C).
- “-CE” model includes Edge Controls license (GE P/N V76982-100010).
- Not safety-rated (SIL/PL not supported).
