ICS TRIPLEX | T8160 | TMR safety controller

2. Technical Specifications

• Safety Integrity Level: SIL 2 (per IEC 61508)—meets safety needs of medium-risk applications
• Architecture: Dual-Modular Redundancy (DMR)—reliable fault tolerance at lower cost
• Processing Power: 2× 32-bit ARM processors (one per DMR module)—fast enough for small-system responses
• I/O Capacity: Up to 128 digital I/O points, 32 analog I/O points—fits small-scale safety systems
• Communication Protocols: Modbus TCP, Ethernet/IP, Profinet—compatible with most industrial control networks
• Operating Voltage: 24 V DC (18–36 V DC range)—stable for industrial power supplies
• Operating Temperature: -20°C to +60°C—works in most indoor and covered industrial environments
• Dimensions: 300 mm × 150 mm × 200 mm (rack-mounted)—compact for small control cabinets
• Response Time: ≤ 20 ms—timely for small-system safety events

3. System Introduction

1. A chlorine concentration sensor and flow sensor in the water line send real-time data to the T8160’s I/O modules.
2. The T8160’s two processors cross-check the data. If chlorine concentration exceeds the safe limit (e.g., 4 ppm), both units confirm the issue.
3. The controller immediately shuts off the chlorine dosing pump, opens a bypass valve to dilute the water, and sends an alarm to the plant’s control room.
4. It shares status with the plant’s PCS, but the safety action runs independently—ensuring safe water supply even if the PCS has a glitch.
