ICS TRIPLEX T8314 is a high-reliability digital output module engineered for safety-critical industrial systems, featuring triple modular redundant (TMR) architecture to meet IEC 61508 SIL 3 compliance and TÜV certification. It offers multiple isolated 24V DC output channels (typically 16–32, optimized for driving field devices like solenoid valves, actuators, and alarms) with robust current-carrying capacity per channel. Designed with galvanic isolation, EMI shielding, and overcurrent/short-circuit protection, it ensures stable operation in harsh environments (oil & gas, power generation, petrochemicals) prone to electrical interference and temperature fluctuations. Seamlessly compatible with ICS Triplex TMR controllers, the module supports hot-swappable installation for minimal downtime and includes built-in diagnostics with LED status indicators for real-time fault monitoring—making it a critical component for safety instrumented systems (SIS) and emergency shutdown (ESD) architectures.
- Manufacturer : ICS Triplex
- Product No. : T8314
- Product type : Trusted TMR Processor
- Voltage Range : 20 to 32V dc
- Heat Dissipation : 80 W
- Use with Chassis : T8100
- Maximum Load : 80 W
- Processor Clock : 100 MHz
- I/O Interface : Triple redundant Inter-Module Bus
- SOE Buffer Size : 1000 events, transferred to CI buffer of 4000 events
- Operating Temperature : 0 °C to 60 °C (32 °F to 140 °F)
- Non-operating Temperature : -25 °C to 70 °C (-13 °F to 158 °F)
- Dimensions (LxWxH) : 30.3 cm x 9.3 cm x 26.6cm
- Weight : 2.94 Kg
- Shipping weight : 4 Kg
