IS200TSVCH1ADC S1CX01H | GE Electric (TMR) servo output module
Product Description
The IS200TSVCH1ADC S1CX01H is a Triple Modular Redundant (TMR) Servo Output Module from GE’s Mark VI Speedtronic series. It provides high-integrity, fault-tolerant control signals to servo valves and proportional valves in turbine systems, converting digital commands into precise analog current outputs (4–20 mA) across three synchronized channels for critical hydraulic/actuation control.
Product Parameters / Specifications:
|
Parameter Category
|
Specification
|
Notes
|
|---|---|---|
|
Manufacturer
|
GE (General Electric)
|
Part of GE Industrial Solutions (GE Vernova)
|
|
Series
|
Mark VI Speedtronic Turbine Control System
|
Compatible with Mark VI
|
|
Module Type
|
TMR Servo Valve Control Output Module
|
Triple-redundant architecture (3 channels per output)
|
|
Part Number
|
IS200TSVCH1ADC S1CX01H
|
ADC = Hardware revision, S1CX01H = Firmware/config suffix |
|
Primary Function
|
Generate redundant 4–20 mA current signals for servo/proportional valves
|
Controls fuel/steam valves, actuators, or hydraulic systems
|
|
Output Channels
|
6 channels (3 TMR groups × 2 outputs each)
|
3 isolated channels per output group (A/B/C)
|
|
Output Signal Type
|
4–20 mA current loop (PWM-driven)
|
Configurable per channel
|
|
Output Resolution
|
16-bit (minimum) per channel
|
High-precision digital-to-analog conversion
|
|
Accuracy
|
±0.1% of full scale (typical)
|
Includes temperature drift compensation
|
|
Output Drive Capability
|
Up to 500 Ω load impedance per channel
|
Supports long cable runs
|
|
Ripple Current
|
< 0.1% peak-to-peak (typical)
|
Critical for sensitive servo valves
|
|
Fault Tolerance
|
2-out-of-3 (2oo3) voting
|
Automatic switch to healthy channels on failure
|
|
Diagnostics
|
• Per-channel open/short detection
• TMR mismatch alarms • Hardware fault LEDs |
Real-time health monitoring
|
|
Isolation
|
• Channel-to-channel: >500V AC
• Channel-to-logic: 1500V AC RMS |
Reinforced isolation for noise immunity
|
|
Configuration
|
Via Mark VI ToolboxST™ software
|
Adjusts output range, filtering, fail-safe states
|
|
Communication
|
VME bus to Mark VI controller
|
Interfaces with
<VPRO> or <TREG> modules |
|
Redundancy Support
|
Hot-swappable with compatible modules
|
Online replacement capability
|
|
Operating Temperature
|
-40°C to +70°C
|
Industrial-grade ruggedization
|
|
Safety Certification
|
Designed for IEC 61508 SIL 2 / SIL 3 (system-level)
|
Compliant with functional safety standards
|
Series:
Part of GE’s Mark VI Speedtronic family for gas/steam turbine control, designed for mission-critical actuation systems.
Key Features:
- Triple Modular Redundancy (TMR): Three independent circuits per output eliminate single points of failure.
- High-Accuracy Current Output: Precision 4–20 mA signals with minimal ripple for valve stability.
- Fault-Adaptive Operation: Automatic 2oo3 voting isolates faulty channels without interruption.
- Integrated Diagnostics: Real-time monitoring of shorts, opens, and channel mismatches.
- Fail-Safe Modes: Configurable fallback states (e.g., hold last value, predefined safe position).
- Hot-Swap Capability: Replace modules during system operation (redundant pairs required).
- Seismic/Vibration Rated: Built for harsh power plant environments.
- Low-Noise Design: Critical for sensitive servo valve operation.
Function/Role:
Converts digital commands from the Mark VI controller into ultra-reliable analog current signals to position hydraulic actuators, fuel valves, or steam valves. Performs continuous TMR validation to ensure signal integrity.
Purpose/Use:
- Critical Flow/Position Control: Fuel metering valves, inlet guide vanes (IGV), bypass valves.
- Turbine Actuation: Governing control, load management, safety shutoff systems.
- Redundant Hydraulic Control: Emergency trip systems, hydraulic fluid management.
- Process Safety: Prevents overspeed/overpressure by precisely modulating fluid flows.
Application Fields:
- Power Generation:
- Gas turbine fuel control (liquid/gas)
- Steam turbine governor valves
- Combined-cycle plant bypass systems
- Oil & Gas:
- Turbine-driven compressor surge control
- LNG plant cryogenic valve control
- Industrial:
- Cogeneration (CHP) fuel/steam regulation
- Petrochemical process control valves
- Marine Propulsion:
- Naval vessel turbine throttle control
- Aeroderivative Turbines:
- Mobile power units, mechanical drive systems
This module ensures fail-operational control for critical turbine valves, leveraging TMR technology to prevent unplanned shutdowns in GE’s Mark VI control platforms. For proper operation, it typically pairs with the <VPRO> (Servo Valve Interface) module.
