IS210MACCH1AKH | GE Electric Mark VIe Communication Controller module
Product Description
The GE IS210MACCH1AKH is a Mark VIe Communication Controller module designed to provide high-speed, redundant communication between control hardware and plant networks in industrial automation systems. It functions as a critical bridge, synchronizing data exchange between controllers, I/O modules, HMIs, and higher-level SCADA systems while ensuring deterministic performance for turbine control, process safety, and real-time monitoring.
Key Features
- Deterministic Communication: Dual-redundant 100 Mbps Ethernet ports with IEEE 1588 Precision Time Protocol (PTP) synchronization.
- Hardware Redundancy: Supports hot-swappable operation for zero-downtime maintenance.
- Fiber-Optic Connectivity: Integrated optical ports (ST connectors) for noise immunity in harsh environments.
- Synchronization Master: Acts as a “SYNCH Lock” source for time-critical control loops.
- Seamless Integration: Native compatibility with Mark VIe, EX2100e, and RX3i systems.
- Advanced Diagnostics: Real-time network health monitoring and fault logging.
Product Specifications
|
Parameter
|
Specification
|
|---|---|
|
Function
|
Network Synchronization & Communication Hub
|
|
Ethernet Ports
|
2x 10/100Base-TX (RJ45, copper)
2x 100Base-FX (ST, fiber-optic) |
|
Protocol Support
|
TCP/IP, SRTP, Modbus TCP, OPC UA
|
|
Synchronization
|
IEEE 1588 PTP (Accuracy: ±500 ns)
|
|
Input Voltage
|
24 V DC ±10% (19–30 V DC range)
|
|
Power Consumption
|
12 W (typical)
|
|
Operating Temperature
|
-30°C to +65°C (-22°F to +149°F)
|
|
Relative Humidity
|
5–95% (non-condensing)
|
|
Certifications
|
CE, UL, cUL, IEC 61800-5-1
|
Series Overview
Part of the GE Mark VIe Integrated Control System, the IS210MACCH1AKH belongs to the MACCH communication module series:
- IS210: Mark VIe hardware family.
- MACCH: Modular Advanced Communication Controller Hub.
- H1: Hardware revision (industrial-grade).
- AKH: Variant with fiber-optic ports and extended synchronization features.
Applications
- Power Plants: Gas/steam turbine control networks, excitation systems (EX2100e).
- Oil & Gas: Compressor station control, safety system data highways.
- Manufacturing: Real-time data aggregation for distributed PLCs.
- Renewables: Wind farm controller synchronization.
- Water Treatment: Plant-wide control network backbone.
Functional Role
- Network Synchronization: Distributes IEEE 1588 timing across controllers for coordinated actions.
- Data Routing: Transfers I/O data between Mark VIe controllers and HMIs/SCADA.
- Redundancy Management: Automatically switches to backup Ethernet/fiber paths during failures.
- Protocol Translation: Bridges legacy (Modbus RTU) and modern (OPC UA) industrial protocols.
Why Choose IS210MACCH1AKH?
- Zero Control Interruption: Redundant ports and hot-swap design ensure continuous operation.
- EMI/RFI Immunity: Fiber-optic links eliminate electrical noise in substations/industrial plants.
- Deterministic Performance: Guarantees sub-millisecond data delivery for critical loops.
- Future-Proof Scalability: Supports >50 controllers per network segment.
There are no reviews yet.
