IS220YAICS1AL | GE Electric Mark VIe Controller Communication Gateway Module
Product Description
The IS220YAICS1AL is a Y-Coupling Interface Communication Module from GE’s Mark VIe Speedtronic series. It functions as a high-speed communication gateway between Mark VIe controllers, I/O modules, and external systems (e.g., DCS, SCADA) using Ethernet and serial protocols for real-time data exchange and system synchronization.
Product Parameters / Specifications
|
Parameter Category
|
Specification
|
|---|---|
|
Manufacturer
|
GE (General Electric)
|
|
Series
|
Mark VIe Speedtronic Turbine Control System
|
|
Module Type
|
Y-Coupling Communication Interface
|
|
Part Number
|
IS220YAICS1AL (
S1AL = Hardware/Firmware Revision) |
|
Primary Function
|
Redundant Ethernet & serial communication bridge for control networks
|
|
Communication Ports
|
– 2x 10/100 Mbps Ethernet (RJ45, IEC 61850-3 compliant)
– 2x RS-232/485 serial ports (software-configurable) |
|
Protocol Support
|
– Ethernet: SRTP, Modbus TCP, IEC 61850, OPC DA/UA
– Serial: Modbus RTU, DNP3.0, IEC 60870-5 |
|
Real-Time Sync
|
IEEE 1588 Precision Time Protocol (PTPv2) for μs-level synchronization
|
|
Data Throughput
|
Up to 100 Mbps (full-duplex)
|
|
Redundancy Support
|
Dual-redundant Ethernet rings (HSR/PRP)
|
|
Isolation Voltage
|
1500V AC (port-to-logic)
|
|
Operating Temperature
|
-40°C to +70°C
|
|
Power Supply
|
24V DC (±10%), 15W max (via Mark VIe backplane)
|
|
Diagnostics
|
Port status LEDs, link activity monitoring, SNMP traps
|
|
Certifications
|
UL 508, CE, IEC 61000-6-4/6-2 (EMC)
|
Series
Part of GE’s Mark VIe Speedtronic platform, designed for distributed control in critical industrial applications.
Key Features
- Multi-Protocol Integration: Unified support for industrial Ethernet & legacy serial protocols.
- Deterministic Communication: <100 μs latency for time-sensitive control loops.
- Dual-Homing Redundancy: Zero-failover switchover (<10 ms) via HSR/PRP.
- Secure Data Exchange: Hardware-based firewall with VLAN segmentation.
- Plug-and-Play: Auto-configuration with Mark VIe ToolboxST™ software.
- Seismic Rating: 5g operational (IEC 60068-2-6).
Function/Role
Acts as a networked communication hub, enabling:
- Real-time data exchange between Mark VIe controllers.
- Integration with plant-wide DCS/SCADA via OPC UA or Modbus TCP.
- Synchronization of distributed I/O modules using PTPv2.
Purpose/Use
- Control Network Bridging: Connects Mark VIe racks in redundant topologies.
- Legacy System Integration: Interfaces with serial-based subsystems (e.g., excitation controls).
- Cybersecurity Enforcement: Implements VLANs and port security for network segmentation.
- Time-Critical Messaging: Ensures synchronized timestamping for protection sequences.
Application Fields
- Power Generation:
- Gas/steam turbine control networks (TMR configurations)
- Plant-wide DCS integration (data historians, alarm management)
- Wind farm controller communication
- Oil & Gas:
- Turbine-compressor anti-surge control synchronization
- LNG process skid monitoring via Modbus RTU
- Industrial Manufacturing:
- High-speed compressor control loops
- Paper mill drive synchronization
- Grid Infrastructure:
- Substation automation (IEC 61850 GOOSE messaging)
- Black start generator control
- Marine:
- Integrated propulsion control systems (IPCS)
- Dynamic positioning data links
This module ensures deterministic, fault-tolerant communication in GE’s Mark VIe systems, critical for synchronizing protection relays, governor controls, and safety interlocks in mission-critical environments. It is typically deployed in pairs for redundancy within control racks like the IC693CHS397.
