IS420ESWBH3A | GE Electric Industrial Ethernet Switches
Product Description
The IS420ESWBH3A is an Industrial Ethernet Switch Blade from GE’s Mark VIe series, designed to provide high-reliability networking for critical control systems. It enables deterministic data exchange between Mark VIe controllers, I/O modules, and plant networks through managed gigabit Ethernet switching with advanced redundancy features.
Product Parameters / Specifications
|
Parameter Category
|
Specification
|
|---|---|
|
Manufacturer
|
GE (General Electric)
|
|
Series
|
Mark VIe Speedtronic Turbine Control System
|
|
Module Type
|
Managed Ethernet Switch Blade
|
|
Part Number
|
IS420ESWBH3A (
H3A = Hardware Revision) |
|
Primary Function
|
Ruggedized industrial switch for control system networking
|
|
Switch Ports
|
– 8x 10/100/1000 Mbps RJ45 ports (copper)
– 2x SFP slots (fiber-optic, 1Gbps) |
|
Switching Capacity
|
12 Gbps
|
|
Forwarding Rate
|
8.9 Mpps (million packets per second)
|
|
MAC Address Table
|
8K entries
|
|
Protocol Support
|
IEEE 1588 (PTPv2), RSTP/MSTP, VLAN (802.1Q), QoS (802.1p), IGMP Snooping
|
|
Redundancy Protocols
|
HSR (High-availability Seamless Redundancy), PRP (Parallel Redundancy Protocol)
|
|
Latency
|
< 3 μs (cut-through switching)
|
|
Power Supply
|
24V DC (±10%) via Mark VIe backplane; 18W max
|
|
Operating Temperature
|
-40°C to +85°C
|
|
Shock/Vibration
|
IEC 60068-2-6 (5g vibration), 15g shock
|
|
Certifications
|
UL 508, CE, IEC 61850-3, IEEE 1613 (substation grade)
|
Series
Part of GE’s Mark VIe Speedtronic platform for industrial control and automation systems.
Key Features
- Military-Grade Resilience: Conformal-coated PCB for humidity/dust resistance (IP40 equivalent).
- Deterministic Performance: Hardware-based QoS prioritizes control traffic (e.g., GOOSE/SV messages).
- Zero-Packet-Loss Redundancy: HSR/PRP support for <1ms failover.
- Precision Timing: IEEE 1588 PTPv2 grandmaster clock synchronization (±100ns accuracy).
- Cybersecurity: Port security, MAC filtering, and VLAN segmentation.
- Hot-Swappable: Tool-less installation in Mark VIe carrier (e.g., IC693CHS397).
Function/Role
- Creates fault-tolerant Ethernet networks within Mark VIe control racks.
- Synchronizes time-sensitive data across controllers, protective relays, and HMIs.
- Segments critical traffic (e.g., turbine control vs. SCADA) via VLANs.
Purpose/Use
- Control Network Backbone: Connects Mark VIe controllers in redundant ring topologies.
- Deterministic Communication: Ensures real-time delivery of protection commands.
- Legacy Integration: Bridges serial-to-Ethernet devices via protocol conversion.
- Cyber-Physical Security: Enforces network segmentation for OT environments.
Application Fields
- Power Generation:
- Turbine control networks (gas/steam/hydro)
- Plant-wide DCS integration (Modbus TCP/OPC UA)
- Wind farm communication backbone
- Oil & Gas:
- Compressor station control rings
- Drilling rig safety system networking
- Grid Infrastructure:
- Substation automation (IEC 61850-9-2LE, GOOSE)
- Phasor Measurement Unit (PMU) data aggregation
- Industrial Manufacturing:
- High-speed motion control networks
- Process safety system (SIL 3) communication
- Transportation:
- Railway signaling systems
- Shipboard integrated power management
The IS420ESWBH3A delivers carrier-grade networking for GE’s Mark VIe systems, enabling microsecond-level synchronization and zero-downtime redundancy in mission-critical applications like turbine protection and grid stability control.
