IS420UCSBH1A | GE Electric Triple redundant safety controller board
Product Function
The IS420UCSBH1A is a triple-redundant safety controller board for GE’s Mark VIeS turbine control system. It executes SIL 3 (Safety Integrity Level 3) certified safety logic for critical turbomachinery protection, performing high-speed monitoring of sensors (vibration, temperature, pressure) and triggering failsafe shutdowns within milliseconds to prevent catastrophic equipment failure.
Product Specifications & Parameters
|
Category
|
Specification
|
|---|---|
|
Manufacturer
|
GE Digital (GE Power Conversion)
|
|
Series
|
Mark VIeS Integrated Safety System
|
|
Type
|
Safety Controller Board
|
|
Redundancy
|
Triple Modular Redundant (TMR) architecture
|
|
Safety Certification
|
SIL 3 (IEC 61508), TÜV Rheinland certified
|
|
Processor
|
32-bit RISC processor (triple-core synchronized)
|
|
Memory
|
256 MB SDRAM, 64 MB Flash
|
|
I/O Interfaces
|
• 2x 10/100Base-T Ethernet (STP RJ45)
• 1x SER expansion port (fiber optic) |
|
Operating Voltage
|
+5V DC ±5% (via VME backplane)
|
|
Power Consumption
|
15W typical
|
|
Operating Temp.
|
-40°C to +70°C (conformal coated)
|
|
Relative Humidity
|
5–95% non-condensing
|
|
Dimensions
|
233 x 160 mm (6U VME form factor)
|
|
Certifications
|
CE, RoHS, ISO 13849, ATEX/IECEx optional
|
Series Information
Part of GE’s Mark VIeS Safety System – designed for critical turbomachinery control. Compatible with:
- Controllers: IS420UCSxHx series
- I/O Packs: IS420PDIAH1A (Analog), IS420ESWBH3A (Discrete)
- Backplanes: IS200VCRCH1B (VME rack)
Key Features
- Triple Modular Redundancy (TMR): Three independent processors voting for fault tolerance.
- SIL 3 Compliance: Meets highest industrial safety standards (1E-9 failure probability).
- Deterministic Execution: 10ms safety scan cycle with <100µs I/O response.
- Built-in Diagnostics: Continuous self-test of CPU, memory, and I/O paths.
- Secure Communications: Encrypted Ethernet protocols (SRTP, Modbus/TCP Safety).
- Voting Mechanisms: 2oo3 (two-out-of-three) logic for shutdown decisions.
- Seismic Resistance: Validated for 5g vibration (IEEE 344).
Role & Purpose
- Critical Protection: Safely shuts down turbines/compressors during overspeed, flameout, or vibration events.
- Fault Tolerance: Isolates failed modules without disrupting operations.
- Data Synchronization: Coordinates with non-safety controllers (e.g., IS420UCSAH1A) via SER fiber links.
- Compliance Engine: Enforces safety logic per API 670, ISO 10494, and NFPA 85 standards.
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Power Generation
|
Gas/steam turbine overspeed protection, boiler flame safeguards
|
|
Oil & Gas
|
Compressor surge control, offshore platform ESD systems
|
|
Marine Propulsion
|
Naval vessel engine safety monitoring, LNG carrier turbine controls
|
|
Industrial Energy
|
Cogeneration plant trip systems, blast furnace gas turbine protection
|
|
Hydrogen/Chemical
|
Electrolyzer safety interlocks, centrifugal compressor anti-surge
|
|
Aviation Test Beds
|
Jet engine test cell emergency shutdown (ESD)
|
Technical Notes
- ⚙️ Configuration: Programmed via ToolboxST™ software with Safety Application Logic (SAL).
- 🔧 Hot-Swap: Supports live insertion/removal in VME racks (IS200VCRCH1B).
- 📡 Networking:
– ETH1: Safety network (peer-to-peer with other UCSB boards)
– ETH2: Engineering/maintenance access - 💡 Status LEDs:
- Green: Normal operation
- Red: Fault in one channel
- Flashing Red: TMR failure (requires shutdown)
- ️ Cyber Security: Integrated firewall with role-based access control.
Safety Rules:
- Must be paired with TMR-rated I/O (e.g., IS420PDOTH4B analog inputs)
- Maximum 12ms safety loop latency (sensor→UCSB→actuator)
- Requires annual validation testing per IEC 61511
System Integration Example
Mark VIeS Safety Rack:
[Slot 1: IS200VCCCH1D (Controller Chassis)]
[Slot 2: IS420UCSBH1A (Safety Controller)]
[Slot 3: IS420PDIAH1A (Analog Input TMR)]
[Slot 4: IS420ESWBH3A (Discrete Output TMR)]
[Slot 5: IS420EPDMG3A (Power Distribution)]
