IS420UCSCH1A | GE Electric Triple redundant safety controller
Product Description
The IS420UCSCH1A is a triple-redundant safety controller from GE’s Mark VIe Series, designed for critical turbine protection systems in power generation. It executes high-integrity safety logic (SIL3 certified) for gas/steam turbines, providing overspeed detection, flame monitoring, and emergency shutdown (ESD) functions to prevent catastrophic failures.
Product Parameters & Specifications (Table)
|
Category
|
Specification
|
|---|---|
|
Model
|
|
|
Manufacturer
|
GE Power / GE Digital Energy
|
|
Series
|
Mark VIe Safety System (Speedtronic Turbine Control)
|
|
Function
|
Triple Modular Redundant (TMR) Safety Controller
|
|
Safety Certification
|
SIL3 (IEC 61508), TÜV-certified
|
|
Processor
|
Three independent 32-bit PowerPC RISC CPUs
|
|
Memory
|
128 MB SDRAM per channel
|
|
I/O Interfaces
|
|
|
Voltage Rating
|
24V DC (±10%)
|
|
Power Consumption
|
25W max (typical)
|
|
Operating Temp.
|
-40°C to +70°C (-40°F to +158°F)
|
|
Certifications
|
UL 508, CE, cULus, DNV, IEC 61000-6 (EMC)
|
|
Status
|
Discontinued (Legacy system – see notes)
|
Key Features
- TMR Architecture: Three parallel channels with 2-out-of-3 (2oo3) voting for fault tolerance.
- High-Speed Peer Sync: Optical TripleBus+ synchronization (<100ns skew).
- Secure Communications: Encrypted Ethernet SRTP protocol for controller-to-I/O networks.
- Hardware Watchdog: Automatic channel shutdown on fault detection.
- Hot-Swap Capable: Supports module replacement without turbine shutdown.
- Diagnostic LEDs: Per-channel status indicators for rapid troubleshooting.
Function & Purpose
Executes safety-critical control algorithms for turbine protection, including:
❶ Overspeed Detection (via magnetic pickups)
❷ Flame Supervision (UV/IR scanner integration)
❸ Vibration Trip Logic
❹ Lube Oil/Fuel System ESD
Ensures failsafe shutdown within milliseconds of hazard detection.
Applications
- Gas Turbine Protection: Emergency shutdown (ESD), combustor monitoring.
- Steam Turbine Safety: Overspeed protection, vacuum trip systems.
- Compressor Stations: Surge control and mechanical integrity monitoring.
- Hydroelectric Plants: Governor failure response.
Application Fields
- Power Generation (Combined-Cycle, Peaking Plants)
- Oil & Gas (Compressor Drives, Offshore Platforms)
- Petrochemical Processing
- District Heating/Cogeneration Facilities
- Marine Propulsion Systems
