Kollmorgen SRB-MS-ILK5 Product Specification
1. Product Overview
The Kollmorgen SRB-MS-ILK5 is a high-precision servo feedback module engineered for seamless integration with Kollmorgen’s AKD and AKD BASIC servo drives. As a critical component in motion control systems, it captures real-time position, velocity, and torque data from absolute encoders and transmits this information to the servo drive with ultra-low latency. Widely applied in industrial automation sectors such as robotics, packaging machinery, semiconductor manufacturing, and CNC machining, this module ensures precise motion control, enabling high-speed and high-accuracy operation of automated equipment.
Compliant with industrial standards including EN 61010-1 and IEC 61800-5-2, the SRB-MS-ILK5 features robust anti-interference design and wide compatibility with mainstream encoder protocols. It maintains stable performance in harsh industrial environments with electromagnetic noise, temperature fluctuations, and vibration, meeting the stringent reliability requirements of precision motion control systems.
2. Technical Parameters & Specifications
|
Category
|
Details
|
|---|---|
|
Product Model
|
Kollmorgen SRB-MS-ILK5
|
|
Product Type
|
Servo Feedback Module (Encoder Interface)
|
|
Compatible Drives
|
Kollmorgen AKD, AKD BASIC Servo Drives
|
|
Supported Encoder Protocols
|
Hiperface DSL; EnDat 2.2; BiSS C; SSI (Absolute/Incremental)
|
|
Position Resolution
|
Up to 23 Bits (Absolute); 1 MHz (Incremental)
|
|
Data Transfer Rate
|
Up to 10 Mbps (Hiperface DSL/EnDat 2.2)
|
|
Input Voltage
|
5 V DC ±10% (From Servo Drive Backplane)
|
|
Power Consumption
|
≤2 W
|
|
Isolation
|
Channel-to-System: 500 V DC (Galvanic Isolation)
|
|
Environmental Ratings
|
Operating Temp: 0°C–55°C; Humidity: 10%–90% (Non-Condensing); Vibration: ≤2 g
|
|
Certifications
|
EN 61010-1; IEC 61800-5-2; CE; UL; RoHS
|
3. Key Features
3.1 High-Precision Feedback Acquisition
With support for up to 23-bit absolute position resolution and 1 MHz incremental signal sampling, the SRB-MS-ILK5 captures ultra-precise motion data. This high resolution ensures minimal position error, enabling applications like semiconductor wafer handling and precision CNC machining to achieve micron-level control accuracy.
3.2 Multi-Protocol Compatibility
The module supports mainstream high-performance encoder protocols including Hiperface DSL, EnDat 2.2, BiSS C, and SSI. This versatility allows it to connect to a wide range of absolute and incremental encoders, eliminating the need for dedicated feedback modules and simplifying system design in mixed-encoder environments.
3.3 Low-Latency Data Transmission
Boasting a data transfer rate of up to 10 Mbps, the module ensures real-time transmission of feedback data to the servo drive. The ultra-low latency (≤10 μs) enables the drive to respond quickly to motion deviations, maintaining stable operation even in high-speed motion scenarios like packaging machinery and robotic arm movement.
3.4 Robust Anti-Interference Performance
Equipped with 500 V DC galvanic isolation and enhanced electromagnetic compatibility (EMC) design, the SRB-MS-ILK5 resists interference from industrial electrical noise and voltage surges. This robust performance ensures reliable data acquisition in harsh environments such as automotive assembly lines and metal processing facilities.
4. Related Kollmorgen Products
-
Kollmorgen SRB-MS-ILK3: Entry-level servo feedback module, supporting basic encoder protocols (SSI/EnDat 2.1) for cost-sensitive applications.
-
Kollmorgen AKD Servo Drive: High-performance servo drive, fully integrating SRB-MS-ILK5 to execute precise motion control strategies.
-
Kollmorgen MCS6000 Motion Controller: Central motion controller, coordinating multiple SRB-MS-ILK5-equipped servo axes for complex multi-axis systems.
-
Kollmorgen S700 Series Encoder: Absolute encoder, paired with SRB-MS-ILK5 to provide high-resolution position feedback for servo systems.
-
Kollmorgen AKD BASIC Servo Drive: Cost-effective servo drive with built-in PLC functions, compatible with SRB-MS-ILK5 for small-scale automation projects.
