Kongsberg PSS 8100184 Product Details
1. Product Overview
The Kongsberg PSS 8100184 is a safety-certified programmable safety system (PSS) engineered for critical safety control in maritime, offshore, and industrial sectors. It serves as a core component for emergency shutdown (ESD), fire and gas (F&G) monitoring, and machinery protection systems—essential for mitigating operational risks, complying with safety standards (e.g., IEC 61508 SIL 3), and protecting personnel and assets in high-risk environments.
Integrating redundant hardware architecture and fail-safe logic processing, it ensures reliable operation even in the event of component failures. Compatibility with Kongsberg’s K-Safe product family and standard industrial safety protocols makes it a trusted solution for safety-critical applications.
2. Technical Parameters (Table)
|
Category
|
Specification
|
|---|---|
|
Device Type
|
Programmable Safety System (PSS) with redundant CPU
|
|
Safety Integrity Level
|
IEC 61508 SIL 3; IEC 61511 SIL 3 (process industry)
|
|
CPU & Memory
|
Dual-core ARM Cortex-A9 (800 MHz); Program memory: 8 GB; Data memory: 4 GB
|
|
I/O Capability
|
Max I/O modules: 32; Digital inputs: Up to 256 (24 V DC); Digital outputs: Up to 128 (24 V DC, 2 A)
|
|
Communication Interfaces
|
2×Ethernet (Modbus TCP/IP, Profinet); 2×RS485 (Modbus RTU); 1×CANopen Safety
|
|
Power Supply
|
Redundant 24 V DC (18–36 V DC); Power consumption: ≤30 W (per CPU)
|
|
Environmental Ratings
|
Operating temp: -20°C to +60°C (-4°F to +140°F); Humidity: 5%–95% (non-condensing); Protection class: IP20 (enclosure)
|
|
Mechanical Design
|
Mounting: 19-inch rack (4U); Housing: Steel (powder-coated); Dimensions: 177 mm (H) × 483 mm (W) × 350 mm (D); Weight: ~12 kg (26.46 lbs)
|
|
Certifications
|
CE; UL 61010-1; IEC 61508 SIL 3; DNV GL; ABS; RoHS compliant
|
3. Product Specifications & Features
3.1 Core Specifications
The Kongsberg PSS 8100184 is optimized for safety-critical control, with SIL 3 certification meeting the strictest safety requirements for offshore ESD and industrial machinery protection. Its redundant CPU architecture ensures no single point of failure—if one CPU fails, the backup takes over within ≤10 ms, maintaining uninterrupted safety control.
Support for up to 32 I/O modules and 256 digital inputs enables integration with diverse safety sensors (e.g., gas detectors, emergency stop buttons) and actuators (e.g., shutdown valves, alarms). The dual Ethernet ports facilitate separate communication paths for safety logic and system diagnostics, enhancing operational reliability.
3.2 Key Features
-
SIL 3 Safety Compliance: Meets IEC 61508/61511 SIL 3 standards, suitable for high-risk applications like offshore oil platform ESD systems.
-
Redundant Architecture: Dual CPU and power supply eliminate single points of failure, ensuring 99.99% operational availability.
-
Scalable I/O Capacity: Up to 32 I/O modules adapt to small-scale (e.g., ship engine room) and large-scale (e.g., refinery) safety systems.
-
Safety-Certified Communication: CANopen Safety and Profinet support ensure reliable data exchange in safety loops.
-
Easy Configuration: Kongsberg Safety Studio software with pre-built safety function blocks simplifies SIL 3-compliant logic development.
4. Other Kongsberg Safety & Automation Products
Kongsberg offers a comprehensive range of safety and automation solutions to complement the PSS 8100184:
-
Kongsberg PSS 8100182: Compact SIL 2 PSS (2U rack) for medium-risk applications (e.g., coastal vessel F&G systems).
-
Kongsberg PSS 8100186: High-density SIL 3 PSS (6U rack) with up to 64 I/O modules for large offshore platforms.
-
Kongsberg K-Safe 200: Safety I/O module (16 DI/8 DO) designed for seamless integration with PSS 8100184.
-
Kongsberg PSS 8100184-M: Maritime-specific variant with DNV GL type approval for shipboard safety systems.
-
Kongsberg Safety Studio: Configuration software for PSS series, enabling SIL-compliant logic design and testing.
