Introduction to WARTSILA LDU-20
LDU-20 Product Overview
The WARTSILA LDU-20 is a dedicated Local Display Unit engineered for real-time status monitoring and data visualization of marine control systems, serving as a critical human-machine interface (HMI) in engine control rooms, propulsion stations, and auxiliary equipment cabins across ferries, offshore platforms, and cargo vessels. As the “visual hub” for Wärtsilä’s core control modules—including the CCM-20 hybrid central controller and UNIC engine management system—it aggregates and presents key operational data such as engine RPM, fuel consumption, valve positions, and battery charge levels in intuitive numeric, graphical, and alarm formats. A standout feature is its 7-inch sunlight-readable color display with anti-glare coating, ensuring clear visibility even in direct sunlight on open bridge decks or poorly lit engine rooms.
LDU-20 Technical Specifications
-
Product Model: LDU-20
-
Product Type: Marine Local Display Unit (Control System HMI)
-
Core Functions: Real-time data visualization, equipment status monitoring, alarm notification, local parameter adjustment, data logging
-
Compatible Systems: WARTSILA CCM-20/CCM-10 Control Modules; WARTSILA UNIC Engine Control System; WARTSILA 20/34 DF Engines; CCM-20 46WCCM20 Hybrid Controller
-
Display Performance: 7-inch TFT color display; Resolution 800×480 pixels; Sunlight-readable (1000 nits brightness); Anti-glare, scratch-resistant coating
-
Data Visualization: Supports numeric readouts, bar graphs, trend charts, and status icons; Customizable screen layouts for different equipment
-
Input/Control: 8 tactile membrane buttons (IP67-rated); Emergency stop input (dry contact); Support for external keyboard/mouse via USB
-
Communication Capability: Wärtsilä CAN bus, Modbus RTU/TCP; RS-485 interface; Data refresh rate ≤100ms; Syncs with ship-wide SCADA
-
Alarm Functions: Audible buzzer (85dB @ 1m); Visual LED indicators (red/yellow/green); Alarm log storage (10,000 events with timestamp)
-
Power Supply: 24V DC ±20% (19.2-28.8V DC); Power consumption ≤15W; No redundant power required (passive data display mode)
-
Protection Features: IP65 front panel rating; ESD protection (±15kV contact); Vibration dampening; Shock resistance 20g (11ms pulse)
-
Operating Environment: Temperature -20°C to +65°C; Humidity 5-95% (non-condensing); Salt fog resistance (complies with IEC 60068-2-11)
-
Mechanical Dimensions: 190mm (W) × 140mm (H) × 50mm (D); Panel mount (standard 19-inch cutout); Weight ~0.8kg
-
Certifications: DNV GL, ABS, LR marine certifications; IEC 60945, CE compliant; IMO MARPOL Annex VI compatible
Recommended WARTSILA Products
-
WARTSILA CCM-20 46WCCM20: Hybrid central control module that transmits real-time load data to LDU-20 for offshore vessel monitoring.
-
WARTSILA 20 DF Engine: Dual-fuel engine whose fuel mode and RPM data are displayed on LDU-20 for crew oversight.
-
WARTSILA ProTouch 10: Propulsion control interface that syncs navigation commands with LDU-20 for unified data presentation.
-
WARTSILA UNIC 5000: Engine control system that sends combustion efficiency data to LDU-20 for performance tuning.
-
WARTSILA FleetViewOnline: Remote platform that replicates LDU-20’s local data for onshore fleet management.
-
WARTSILA ESD-300: Emergency shutdown system that triggers LDU-20’s high-priority alarm for critical fault notification.
-
WARTSILA MCM 800: Main engine control module whose sensor data is aggregated and displayed on LDU-20.
-
WARTSILA WCP Propeller System: Controllable pitch propeller whose thrust data is visualized on LDU-20 for propulsion optimization.
