Introduction to ELAU PMC-2/11/08/000/01/03/00/00/00
Product Description
The ELAU PMC-2/11/08/000/01/03/00/00/00 is a high-performance modular motion controller designed for precision automation in industrial machinery, particularly in packaging, printing, and material handling applications. As part of Schneider Electric’s ELAU range (now integrated into the Lexium Motion range), this controller combines advanced motion control capabilities with flexible I/O integration, making it ideal for complex multi-axis systems requiring synchronized operation and high throughput.
The model designation “PMC-2/11/08/000/01/03/00/00/00” breaks down its key specifications: “PMC-2” indicates a 2-axis base controller, “11” denotes a 110V AC power supply, “08” specifies 8 digital inputs, and the subsequent codes define I/O configurations, communication options, and hardware variants. This controller is engineered to deliver sub-millisecond synchronization between axes, supporting electronic gearing, camming, and interpolated motion profiles—critical for applications like label printing or robotic packaging where precise coordination is essential. Its modular design allows easy expansion with additional I/O modules or axis cards, adapting to evolving production needs.
Technical Parameters
- Axis Capacity: 2 axes (expandable to 6 axes with additional modules)
- Control Modes: Position, velocity, torque, electronic gearing, camming, and interpolated motion
- Processor: 32-bit DSP with 400 MHz clock speed
- Memory: 512 KB RAM; 2 MB flash memory (for program storage)
- Power Supply: 110V AC (90-132V AC, 50/60Hz); power consumption ≤50W
- Digital Inputs: 8 channels (24V DC, PNP, 5mA); response time ≤10µs
- Digital Outputs: 4 channels (24V DC, 0.5A max per output)
- Feedback Support:
-
- Encoders: Incremental (TTL, 5V) up to 1 MHz
-
- Absolute encoders: SSI (up to 1 Mbps)
- Communication Interfaces:
-
- CANopen (DS 301/402) for drive communication
-
- RS232 for programming and diagnostics
-
- Optional: Ethernet (Modbus TCP/IP) via expansion module
- Motion Performance:
-
- Positioning accuracy: ±0.1 encoder counts
-
- Maximum velocity: 10,000 RPM (with compatible drives)
-
- Synchronization error: ≤1µs between axes
- Operating Temperature: 0°C to +55°C (32°F to +131°F)
- Storage Temperature: -20°C to +70°C (-4°F to +158°F)
- Relative Humidity: 5-95% RH (non-condensing)
- Vibration Resistance: 10-500Hz, 1g peak (IEC 60068-2-6)
- Protection Rating: IP20 (module); IP54 when mounted in a sealed enclosure
- Dimensions: 120mm × 160mm × 100mm (W × H × D)
- Weight: Approximately 1.2 kg
- Certifications: CE, UL 508, IEC 61131-2, RoHS
Usage Methods
- Installation:
-
- Mount the controller on a DIN rail in a control cabinet, ensuring vertical orientation for heat dissipation.
-
- Provide a minimum clearance of 50mm around the module to avoid overheating, especially when using expansion modules.
-
- Install in a dry environment away from direct sunlight and high-voltage cables to minimize electromagnetic interference.
- Wiring and Connection:
-
- Connect the 110V AC power supply to the dedicated terminal, using a 1A fused circuit and twisted-pair cable.
-
- Wire digital inputs to sensors (e.g., limit switches, photoeyes) using 24V DC wiring, ensuring correct polarity for PNP signals.
-
- Connect digital outputs to actuators (e.g., solenoids, relays) with current ratings ≤0.5A per channel.
-
- Link to servo drives via CANopen, using shielded twisted-pair cable with a 120Ω termination resistor at both ends.
-
- Connect encoders to feedback ports, matching signal levels (TTL) and ensuring proper grounding of encoder shields.
- Programming and Configuration:
-
- Use Schneider Electric’s MotionWorks IEC software (compliant with IEC 61131-3) to program motion sequences in structured text or function block diagrams.
-
- Configure axis parameters (e.g., motor type, encoder resolution, PID gains) via the software’s configuration wizard.
-
- Define synchronization profiles, such as electronic cams for packaging machines, using the built-in cam editor.
-
- Test motion profiles in simulation mode before deployment, verifying axis coordination and I/O response.
- Operation and Maintenance:
-
- Power on the controller and check the status LED (green for normal operation; red for faults).
-
- Monitor axis performance via the software’s real-time oscilloscope, tracking position error and velocity.
-
- Perform monthly inspections: check wiring connections for tightness, clean dust from ventilation slots, and verify CANopen communication status.
-
- Back up programs to a PC via RS232 or Ethernet (if equipped) to prevent data loss.
-
- Update firmware annually using MotionWorks IEC to access new features and performance improvements.
System Introduction
The ELAU PMC-2/11/08/000/01/03/00/00/00 operates as the core of precision motion control systems, integrating four key layers:
- Motion Control Layer: The DSP executes high-speed control algorithms, calculating torque commands and position setpoints for each axis to maintain synchronization.
- I/O Layer: Digital inputs capture real-time sensor data (e.g., product presence), while outputs trigger actuators (e.g., grippers) in coordination with motion sequences.
- Communication Layer: CANopen facilitates seamless data exchange with servo drives, enabling precise speed and position control with minimal latency.
- Programming Layer: IEC 61131-3 compliance allows flexible logic design, from simple point-to-point moves to complex cam profiles for dynamic applications.
In a label printing machine, the controller synchronizes two axes: one driving the print head and another feeding label stock. It uses electronic gearing to maintain a fixed ratio between print speed and feed rate, ensuring labels align with printed content. Digital inputs from a photoeye detect label edges, triggering the controller to adjust feed velocity dynamically, while outputs activate inkjet nozzles at precise intervals—all coordinated within microseconds to maintain print quality at high speeds.
Related Models in the Series
- ELAU PMC-2/21/08/000/01/03/00/00/00: 2-axis controller with 230V AC power supply, suitable for regions with 220-240V electrical systems.
- ELAU PMC-4/11/16/000/01/03/00/00/00: 4-axis variant with 16 digital inputs, ideal for larger packaging lines requiring additional sensor integration.
- ELAU PMC-2/11/08/000/01/05/00/00/00: Includes Ethernet (Modbus TCP/IP) for integration with SCADA systems in factory-wide automation networks.
- ELAU PMC-2/11/08/000/02/03/00/00/00: Features analog I/O (4-20mA) for variable control (e.g., pressure regulation in material handling).
- ELAU PMC-6/11/24/000/01/03/00/00/00: 6-axis controller with 24 digital inputs, designed for complex multi-axis machinery like robotic assembly cells.
- ELAU PMC-2/11/08/000/01/03/01/00/00: Explosion-proof variant (ATEX Zone 2) for hazardous environments such as chemical packaging lines.
