TEWS TIP 700-10 Product Specification
1. Product Overview
The TEWS TIP 700-10 is a high-performance PCI Express (PCIe) Gen 3 x2 industrial network interface module tailored for mission-critical embedded systems. Specialized in seamless integration between host controllers and industrial Ethernet networks, it serves as a core connectivity component in applications such as industrial automation, aerospace ground support, and smart factory control systems. By combining high-speed data transmission with rugged design and protocol flexibility, this module ensures reliable communication in harsh industrial environments where downtime risks are unacceptable.
Compliant with international standards including IEEE 802.3 (Ethernet), PCIe Base Specification 3.0, and EN 61000-6-2 (industrial EMC), the TIP700-10 features enhanced anti-interference performance, wide temperature adaptability, and seamless OS integration. It supports major real-time operating systems (RTOS) and industrial protocols, providing engineers with a flexible and cost-effective solution for complex network connectivity tasks.
2. Technical Parameters & Specifications
|
Category
|
Details
|
|
Product Model
|
TEWS TIP700-10
|
|
Product Type
|
PCIe Gen 3 x2 Industrial Network Interface Module
|
|
PCIe Compliance
|
PCIe Base Specification 3.0; Gen 3 x2 Lane Configuration
|
|
Network Standards
|
IEEE 802.3ab (1000Base-T), IEEE 802.3u (100Base-TX), IEEE 802.3 (10Base-T)
|
|
Network Ports
|
4×RJ45 Ports; Auto-MDI/MDI-X; Supports Link Aggregation (LACP)
|
|
Data Transfer Rate
|
10/100/1000 Mbps (Auto-Negotiation)
|
|
Supported Protocols
|
PROFINET, EtherCAT, Modbus TCP, TCP/IP, UDP; Custom Protocol Support via API
|
|
Onboard Memory
|
64 MB DDR4 SDRAM (Data Buffering); 8 MB Flash (Firmware Storage)
|
|
Isolation
|
2.5 kV DC (Port-to-Ground); 1 kV DC (Port-to-Port)
|
|
Power Consumption
|
Typical: 10 W; Maximum: 14 W (12 V DC from PCIe Slot)
|
|
Environmental Ratings
|
Operating Temp: -40°C–85°C; Humidity: 5%–95% (Non-Condensing); Vibration: 10–2000 Hz, 15 g
|
|
Certifications
|
PCIe 3.0; IEEE 802.3; EN 61000-6-2; UL 60950-1; CE; RoHS
|
3. Key Features
3.1 Integrated Multifunctional Design
Equipped with 4 auto-negotiating RJ45 ports, the module supports 10/100/1000 Mbps data rates and auto-MDI/MDI-X crossover, adapting to diverse industrial network infrastructures. Link Aggregation Control Protocol (LACP) support enables combining multiple ports for increased bandwidth (up to 4 Gbps) and network redundancy, critical for high-availability systems like smart factory control networks.
3.2 High-Precision Measurement & Control
Optimized for real-time industrial applications, the TIP700-10 achieves a deterministic latency of ≤4 μs for UDP/IP packets and ≤8 μs for PROFINET/EtherCAT frames. This low-latency performance ensures timely data transmission in time-sensitive scenarios such as motion control and real-time process monitoring, where delay variations can compromise system precision.
3.3 SIL 2 Safety & Isolation
The module supports a wide range of industrial Ethernet protocols including PROFINET, EtherCAT, and Modbus TCP, enabling seamless integration with legacy and modern industrial control systems. The 64 MB DDR4 SDRAM provides dedicated data buffering to prevent packet loss during peak network traffic, while built-in CRC32 error correction ensures data integrity in noisy industrial environments.
3.4 Rugged Industrial Reliability
With 2.5 kV DC galvanic isolation and enhanced EMC performance (EN 61000-6-2), the module resists electromagnetic interference (EMI) and voltage surges common in industrial settings. Its ruggedized design operates reliably in extreme temperatures (-40°C–85°C) and high vibration (15 g), making it suitable for harsh environments like offshore oil platforms, aerospace test facilities, and heavy manufacturing plants.
