TEWS TIP866-10 Product Specification
1. Product Overview
The TEWS TIP866-10 is a high-speed PCI Express (PCIe) Gen 3 x2 serial communication module tailored for industrial embedded and real-time systems. Specialized in deterministic, long-distance data transmission via fiber optic and copper interfaces, it acts as a critical connectivity bridge in applications such as aerospace telemetry, industrial process control, and defense electronics. By combining multi-protocol support with rugged design and low-latency performance, this module ensures reliable data exchange in mission-critical environments where communication integrity and timing precision are non-negotiable.
Compliant with international standards including PCIe Base Specification 3.0, EN 61000-6-2 (industrial EMC), and IEC 61508 (SIL 2), the TIP866-10 features galvanic isolation, wide temperature adaptability, and seamless integration with major real-time operating systems (RTOS). It comes with a comprehensive software development kit (SDK), offering engineers a flexible and cost-effective solution for complex serial communication tasks.
2. Technical Parameters & Specifications
|
Category
|
Details
|
|
Product Model
|
TEWS TIP866-10
|
|
Product Type
|
PCIe Gen 3 x2 High-Speed Serial Communication Module
|
|
PCIe Compliance
|
PCIe Base Specification 3.0; Gen 3 x2 Lane Configuration
|
|
Serial Interfaces
|
4 Channels; 2×SFP+ (Fiber Optic), 2×RS-485 (Copper); Configurable
|
|
Data Transfer Rate
|
Up to 10 Gbps per SFP+ Channel; Up to 10 Mbps per RS-485 Channel
|
|
Supported Protocols
|
HDLC, PPP, Frame Relay, TCP/IP, Custom Serial Protocols via API
|
|
Synchronization
|
External Clock (0–20 MHz); Internal Clock (±25 ppm Accuracy)
|
|
Onboard Memory
|
64 MB DDR4 SDRAM (Dedicated Tx/Rx Buffering)
|
|
Isolation
|
5 kV DC (Channel-to-Ground); 2.5 kV DC (Channel-to-Channel)
|
|
Power Consumption
|
Typical: 12 W; Maximum: 15 W (12 V DC from PCIe Slot)
|
|
Environmental Ratings
|
Operating Temp: -40°C–85°C; Humidity: 5%–95% (Non-Condensing); Vibration: 10–2000 Hz, 15 g
|
|
Certifications
|
PCIe 3.0; IEC 61508 (SIL 2); EN 61000-6-2; UL 60950-1; CE; RoHS
|
3. Key Features
3.1 Hybrid Serial Connectivity
The module integrates 2 SFP+ fiber optic ports and 2 RS-485 copper ports, supporting both high-speed (10 Gbps) long-distance transmission and cost-effective short-range communication. SFP+ ports enable transmission distances up to 40 km (single-mode fiber), while RS-485 ports support multi-drop networks for industrial sensors and actuators.
3.2 Deterministic Low Latency
Optimized for real-time systems, the TIP866-10 achieves a deterministic latency of ≤3 μs for SFP+ channels and ≤10 μs for RS-485 channels. This consistent performance is critical for applications like aerospace flight data transmission and industrial motion control, where delay variations can compromise system safety.
3.3 Advanced Synchronization
Equipped with high-accuracy internal clock (±25 ppm) and external clock input (0–20 MHz), the module ensures precise synchronization across distributed systems. This capability is essential for multi-node applications like industrial process control, where timing consistency directly impacts data correlation and control accuracy.
3.4 Robust Safety & Ruggedness
SIL 2 certification and 5 kV DC galvanic isolation protect the module from voltage surges and cross-channel interference, ensuring compliance with industrial safety standards. Its ruggedized design withstands extreme temperatures (-40°C–85°C), high vibration (15 g), and electromagnetic interference (EMI), making it suitable for harsh environments like offshore oil rigs and military vehicles.
4. Related TEWS Products
-
TEWS TIP866-20: 8-channel serial module with 4 SFP+ and 4 RS-485 ports, for high-density communication systems.
-
TEWS TPMC871-10: Multifunctional I/O module, ideal for pairing with TIP866-10 to integrate data acquisition and serial communication.
-
TEWS TIP810-10R: Redundant PCIe interface module, enhancing TIP866-10-based systems with fault-tolerant connectivity.
-
TEWS TPM100-02: Precision timing module, ensuring synchronized data transmission across TIP866-10 nodes.
-
TEWS SDK-SerialPro: Advanced software development kit, providing protocol configuration tools and APIs for TIP866 series modules on Linux, VxWorks, and Windows Embedded.
