TEWS TPMC871-10 Product Specification
1. Product Overview
The TEWS TPMC871-10 is a highly integrated PCI Express (PCIe) Gen 2 x1 multifunctional I/O module tailored for industrial embedded and real-time systems. It consolidates analog, digital, and counter/timer functions in a single board, serving as a versatile data acquisition and control solution for applications such as industrial process monitoring, aerospace testing, and automotive electronics. By combining multiple I/O capabilities with rugged design and low-latency performance, this module simplifies system architecture, reduces hardware footprint, and ensures reliable operation in mission-critical environments.
Compliant with international standards including PCIe Base Specification 2.0, EN 61000-6-2 (industrial EMC), and IEC 61508 (SIL 2), the TPMC871-10 features high measurement accuracy, galvanic isolation, and wide environmental adaptability. It seamlessly integrates with major embedded operating systems, providing engineers with a cost-effective and flexible I/O solution for complex industrial control tasks.
2. Technical Parameters & Specifications
|
Category
|
Details
|
|
Product Model
|
TEWS TPMC871-10
|
|
Product Type
|
PCIe Gen 2 x1 Multifunctional I/O Module (SIL 2 Certified)
|
|
PCIe Compliance
|
PCIe Base Specification 2.0; Gen 2 x1 Lane Configuration
|
|
Analog Input (AI)
|
8 Channels, 16-bit Resolution; ±10 V DC Range; Accuracy ±0.01% FS
|
|
Analog Output (AO)
|
4 Channels, 16-bit Resolution; 0–10 V DC Range; Load ≤1 kΩ
|
|
Digital I/O (DIO)
|
16 Channels (Configurable as Input/Output); 24 V DC; 200 mA per Channel
|
|
Counter/Timer
|
2 Channels; 32-bit; Frequency Range 0–1 MHz
|
|
Isolation
|
AI/AO: 2.5 kV DC; DIO: 500 V DC (Channel-to-Ground)
|
|
Power Consumption
|
Typical: 8 W; Maximum: 12 W (12 V DC from PCIe Slot)
|
|
Environmental Ratings
|
Operating Temp: -40°C–85°C; Humidity: 5%–95% (Non-Condensing); Vibration: 10–2000 Hz, 10 g
|
|
Certifications
|
PCIe 2.0; IEC 61508 (SIL 2); EN 61000-6-2; UL 60950-1; CE; RoHS
|
3. Key Features
3.1 Integrated Multifunctional I/O
Combining 8 AI, 4 AO, 16 configurable DIO, and 2 counter/timer channels in one module, the TPMC871-10 eliminates the need for multiple single-function boards. This integration reduces system complexity, lowers power consumption, and saves PCIe slot space—critical for compact embedded systems like portable test equipment and onboard controllers.
3.2 High-Precision Measurement & Control
The 16-bit analog channels deliver ±0.01% full-scale accuracy for AI measurements, ensuring precise capture of process variables like temperature and pressure. The AO channels provide stable output signals with low noise (≤10 mVpp), enabling fine control of actuators such as valves and motors in precision manufacturing applications.
3.3 SIL 2 Safety Compliance & Isolation
Certified for SIL 2 operation, the module integrates built-in fault detection (e.g., open-circuit AI monitoring) and 2.5 kV DC galvanic isolation for analog channels. This design prevents electrical interference between the module and field devices, protects the host system from voltage surges, and ensures compliance with safety standards for industrial control systems.
3.4 Rugged & Reliable for Harsh Environments
Engineered to withstand extreme temperatures (-40°C–85°C) and high vibration, the TPMC871-10 is suitable for harsh operating conditions such as aerospace ground support, oilfield monitoring, and industrial factory floors. The rugged PCB design and industrial-grade components ensure long-term reliability with a mean time between failures (MTBF) of over 500,000 hours.
4. Related TEWS Products
-
TEWS TPMC871-20: Enhanced multifunctional I/O module with 16 AI/8 AO channels and 32 DIO, for high-channel-count applications.
-
TEWS TPMC831-10: PCIe Gen 2 x1 analog input module with 32 channels, specialized for high-density data acquisition.
-
TEWS TPMC841-10: PCIe Gen 2 x1 digital I/O module with 64 channels and 1 A per channel, for heavy-duty industrial control.
-
TEWS TIP114-10: PCIe Gen 2 x4 interface module, ideal for pairing with TPMC871-10 to extend network connectivity in distributed systems.
-
TEWS SDK-IO: Software development kit for TPMC series modules, providing drivers, APIs, and configuration tools for Linux, VxWorks, and Windows Embedded.
