TRICONEX DO3626X Digital Output Module Introduction
1. Product Overview
The TRICONEX DO3626X is a high – performance digital output module meticulously designed for industrial automation and control systems. It plays a pivotal role in ensuring reliable and precise control across a diverse array of applications, such as manufacturing processes, machinery control, and many other industrial scenarios. This module is an integral part of the TRICONEX safety instrumented system (SIS) and belongs to the Trident series, featuring a triple modular redundancy (TMR) architecture. This unique architecture is a key strength as it ensures continuous operation even in the face of a fault, significantly enhancing the system’s reliability and availability.
2. Product Technical Parameters
2.1 Electrical Parameters
- Operating Voltage: It operates on 24 VDC, which is a commonly used voltage level in industrial settings, providing stable power supply for the module’s operation.
- Number of Channels: Equipped with 16 channels, the DO3626X can handle multiple output tasks simultaneously, increasing the efficiency of controlling various loads.
- Channel Configuration: The module has a common return configuration, which simplifies the wiring and connection process in industrial control systems.
- Output Type: It offers dry contact / solid – state relay output types. Dry contact outputs are useful for applications where electrical isolation is crucial, while solid – state relays provide fast switching times and high reliability.
- Max Switching Current: Each channel is capable of handling a maximum switching current of 0.5 A. This current rating allows the module to drive a wide range of industrial loads, from small – scale sensors to certain types of actuators.
- Isolation Voltage: With an isolation voltage of 1500 VAC, the module effectively separates the control side from the load side, protecting the control system from electrical interference and potential damage caused by voltage surges in the load circuit.
2.2 Environmental Parameters
- Operating Temperature: The DO3626X can function properly in a wide temperature range from – 40 °C to + 85 °C. This wide temperature tolerance makes it suitable for use in various industrial environments, including those in extremely cold regions or areas with high – temperature industrial processes.
- Storage Temperature: It can be stored in an environment with temperatures ranging from – 40 °C to + 85 °C, ensuring its long – term usability and durability even when not in active operation.
2.3 Mechanical Parameters
- Dimensions: The module has compact dimensions, typically around 120 mm x 80 mm x 60 mm (height x width x depth). This compact size makes it easy to install in control cabinets with limited space.
- Weight: It is lightweight, weighing approximately 0.5 kg, which also contributes to its easy installation and handling.
2.4 Certification
The DO3626X complies with several international safety and quality standards, including IEC 61508, SIL 3, CE, UL, and ATEX certifications. These certifications ensure that the module can be safely used in different industries, especially those with strict safety requirements, such as the oil and gas, chemical, and power generation industries.
3. Usage Method
3.1 Installation
- Mounting: The module is designed to be mounted on a DIN rail, which is a common industrial mounting method. First, select an appropriate DIN rail in the control cabinet. Then, carefully insert the DO3626X module onto the DIN rail until it clicks into place, ensuring a secure connection.
- Wiring: Connect the power supply wires to the designated power terminals on the module, making sure to observe the correct polarity for the 24 VDC power input. Next, connect the output wires from the module to the external devices that need to be controlled. For each channel, connect the positive output terminal of the channel to the input of the load device, and the common return terminal to the appropriate reference point in the load circuit.
3.2 Configuration
- Software Configuration: The DO3626X module may require software configuration depending on the specific application. This can be done through the control system’s programming software. In the software, define the function of each channel, such as whether it is used to control a motor, a valve, or a signal light. Also, set parameters related to the output type (e.g., for solid – state relay or dry contact operation), and configure any communication – related settings if the module is part of a networked control system.
- Output Settings: Set the output state (active – high or active – low) according to the requirements of the external devices. For example, if the load device is designed to be activated when a high – level signal is received, configure the corresponding channel for active – high output.
3.3 Operation
Once installed and configured, the DO3626X module starts to receive digital control signals from the control system. When a digital signal is received on a particular channel, the module converts this signal into a physical output. For example, if the control system sends a high – level digital signal to a channel configured to control a motor starter, the module will close the dry contact or activate the solid – state relay in that channel, thereby energizing the motor starter and starting the motor.
4. System Introduction
4.1 TRICONEX Safety Instrumented System (SIS)
The DO3626X is an important component of the TRICONEX SIS. The SIS is designed to prevent or mitigate dangerous events in industrial processes. The TMR architecture of the DO3626X module, as part of the SIS, provides a high level of fault tolerance. In a TMR system, the module has three identical processing channels. Each channel processes the input signals independently, and the results are compared. If one channel fails, the system can still operate correctly using the results from the two remaining healthy channels. This architecture significantly reduces the probability of system failure due to component faults.
4.2 Communication Capabilities
- Modbus RTU and TCP: The DO3626X supports Modbus RTU (Remote Terminal Unit) and TCP (Transmission Control Protocol) communication protocols. Modbus RTU is a widely used serial communication protocol in industrial automation, allowing the module to communicate with other Modbus – compatible devices over a serial link, such as RS – 485. Modbus TCP, on the other hand, enables communication over an Ethernet network, providing faster data transfer speeds and the ability to integrate the module into larger, network – based control systems.
- Other Protocols: In addition to Modbus, the module may also support other communication protocols depending on the specific configuration, such as Profibus. This versatility in communication protocols makes it easy to integrate the DO3626X into existing or new industrial automation systems, regardless of the communication standards already in use in the plant.
4.3 Integration with Other Modules
The DO3626X can be seamlessly integrated with other TRICONEX system modules, such as input modules, controller modules, and communication modules. For example, it can receive control signals from a TRICONEX controller module, which has processed input data from various input modules. This integration allows for a comprehensive and coordinated control of industrial processes, where different types of signals (input and output) are managed and processed within the same system framework.
