V7768-320000 3509301007768-320000A0 | GE Electric DC Backup Battery Module
Product Description
The GE V7768-320000 (3509301007768-320000A0) is a High-Integrity DC Backup Battery Module designed for uninterrupted power supply in critical industrial control systems. It ensures continuous operation of safety controllers (e.g., Mark VIe) during mains power failures by delivering regulated DC power, enabling safe shutdowns, data retention, and system stability.
Key Features
- Extended Runtime: Nickel-Cadmium (NiCd) chemistry for 8+ hours of backup at full load.
- Hot-Swappable Design: Allows replacement without system shutdown.
- Intelligent Monitoring: Onboard voltage/current sensors with fault alerts via control network.
- SELV Compliance: Safety-Extra Low Voltage (60V DC) for reduced arc/flash risks.
- Corrosion Resistance: Sealed IP65 enclosure for harsh environments (dust, humidity, chemicals).
- Zero Maintenance: Non-spillable construction with 10-year design life.
Product Specifications
|
Parameter
|
Specification
|
|---|---|
|
Model Variant
|
3509301007768-320000A0 (Commercial P/N)
|
|
Nominal Voltage
|
110 V DC
|
|
Capacity
|
8 Ah @ 20°C (C10 rating)
|
|
Backup Duration
|
≥ 8 hours (100% load)
|
|
Operating Temperature
|
-30°C to +60°C (-22°F to +140°F)
|
|
Charging Voltage
|
126–132 V DC (Constant voltage float)
|
|
Terminal Type
|
Heavy-duty screw terminals (Cu alloy)
|
|
Dimensions
|
210 × 180 × 380 mm (W×H×D)
|
|
Weight
|
18.5 kg (40.8 lbs)
|
|
Certifications
|
UL 1973, IEC 62133, CE, RoHS
|
Series Overview
Part of GE’s Critical Power Backup Series, this module integrates with:
- V7768 Series: Industrial UPS/battery systems for Mark VIe/RX3i platforms.
- 350930100: GE’s standardized power accessory prefix.
- A0 Revision: Optimized for Mark VIe cabinets with DIN-rail mounting.
Applications
- Turbine Control Systems: Backup power for Mark VIe safety controllers during grid failures.
- Substation Automation: Supports relay protection systems.
- Process Safety: Emergency power for ESD/IPS valves in oil & gas.
- Marine Propulsion: Backup for dynamic positioning controllers.
- Nuclear Facilities: Class 1E safety system compliance.
Functional Role
- Power Bridging: Seamlessly powers controllers within 5 ms of AC loss.
- Voltage Regulation: Maintains ±1% voltage stability during discharge.
- Health Diagnostics: Reports capacity degradation via <0> controller interface.
- Failsafe Preservation: Prevents data corruption during shutdown sequences.
Why Choose V7768-320000?
- Mission-Critical Reliability: 99.999% uptime in GE’s field-proven turbine installations.
- Scalable Stacking: Parallel connection for higher voltage/capacity needs.
- Fire Safety: UL-certified flame-retardant casing with thermal runaway protection.
- Legacy Support: Compatible with Mark V, VI, and VIe systems via adapters.
