Introduction to WOODWARD 8200-1312
8200-1312 Product Overview
The WOODWARD 8200-1312 is a high-performance digital control module, serving as a core component in the brand’s 8200 series for industrial power system regulation. It integrates advanced control algorithms, real-time monitoring, and flexible configuration capabilities to deliver precise speed and load management for diesel generators, steam turbines, and gas turbines. Widely applied in power generation, oil & gas, and marine engineering, it stabilizes the speed of diesel generator sets in backup power systems, optimizes the output of steam turbines in thermal plants, and ensures load balance for gas turbine-driven compressors in pipelines. Its modular design features an IP65-protected aluminum housing, withstanding harsh industrial conditions such as high temperature, vibration, and humidity. Equipped with an RS485 communication interface, it seamlessly connects with WOODWARD 8200 series controllers and DCS systems, enabling remote parameter configuration and fault diagnosis to enhance operational efficiency.
8200-1312 Technical Specifications
-
Product Type: Industrial digital control & speed regulation module (8200 series)
-
Core Functions: Precision speed control, load distribution, real-time monitoring, fault self-diagnosis
-
Application Compatibility: Diesel generators, steam turbines, gas turbines, industrial compressors
-
Input Signal: 0-10V DC voltage signal; 4-20mA current signal
-
Output Signal: 0-10V DC voltage output; current capacity up to 2A
-
Control Performance: Speed regulation accuracy ±0.1%; response time <10ms
-
User Interface: Backlit LCD display for real-time data; support for on-site parameter adjustment
-
Communication Interface: RS485; compatible with standard industrial communication protocols
-
Power Supply: 24V DC nominal; 18-36V DC wide input range; typical power consumption 20W
-
Operating Environment: Temperature -40°C to +85°C; humidity 0-95% (non-condensing); vibration resistance 5g
-
Physical Dimensions: 150mm×100mm×60mm (L×W×H); weight ~2.0kg; IP65 protection rating
-
Certifications: CE, RoHS certified; compliant with industrial control safety standards
Recommended WOODWARD Related Models
-
WOODWARD 8200-1302: Servo position controller, specialized for turbine valve positioning with high precision
-
WOODWARD 505E: Advanced turbine controller, pairs with 8200-1312 for large-scale steam turbine systems
-
WOODWARD 2301A: Cost-effective speed governor, ideal for small diesel generator sets
-
WOODWARD Varistroke-DX: Electro-hydraulic actuator, executes control signals from 8200-1312
-
WOODWARD ProTech TPS: Turbine protection system
-
WOODWARD 9907-164: 505 series turbine controller
-
WOODWARD APECS® 4500: Programmable engine controller
-
WOODWARD DPG 2200: Generator paralleling controller
-
WOODWARD Flex500: Multi-turbine control system
-
WOODWARD K-Series Actuators: Electric throttle units, respond to speed control commands from the module
-
WOODWARD LinkNet-HT: Distributed I/O module, expands 8200-1312’s monitoring capabilities
-
WOODWARD 1712 EPG: All-in-one governing system, cost-effective alternative for small turbomachinery
-
WOODWARD 5009 TMR: Triple-redundant controller, upgrades safety for critical systems using 8200-1312
-
WOODWARD 8237-2597: Digital regulator, complements 8200-1312 in auxiliary control loops
-
WOODWARD CPC-II: Current-pressure converter, translates 8200-1312 signals to hydraulic valve control
